CHERY BUGGY UP KART BEST

Specifications

Chery Engine 1500cc 4x4 Amazing dune buggy

                          Detailed  Specification

                                     DIMENSIONS

Overall Length--------------------------------------------------------------------------------------------------3140mm

Overall Width -------------------------------------------------------------------------------------------------- 1850mm

Overall Height ------------------------------------------------------------------------------------------------- 1580mm

Wheelbase --------------------------------------------------------------------------------------------------------2450mm

Front Track ------------------------------------------------------------------------------------------------------ 1375mm

Rear Track --------------------------------------------------------------------------------------------------------1570mm

Ground Clearance ------------------------------------------------------------------------------------------------310mm

                                               ENGINE

Type -------------------------------------------------------------------------------4 Cylinder,4-Strokes,water cooled

Bore x Stroke ---------------------------------------------------------------------------------------------77.4×79.52mm

Displacement ------------------------------------------------------------------------------------------------------1497mL

Compression ratio ------------------------------------------------------------------------------------------------10.5:1

Carburetor --------------------------------------------------------------------------------------- Electric Fuel Injection

Max Power ------------------------------------------------------------------------------------------------80KW/6000rpm

Maximum Torque ------------------------------------------------------------------------------------140/3000Nm/r/min

Fule consumption----------------------------------------------------------------------------------------------6.2L/100km

Starting ----------------------------------------------------------------------------------------------------------- Electric

Ignition -------------------------------------------------------------------------------------------- Electric Fuel Injection

Lubrication -------------------------------------------------------------------------------------------- Force & Splash

Transmission ------------------------------------------------------------------------ Manual clutch, 5 shift/Reverse

Fuel type ------------------------------------------------------------------------------------------------ RQ93 (unleaded)

Engine oil ----------------------------------------------------------------------------------------------------- SAE-10W/30

Gear oil ----------------------------------------------------------------------------------------------------- GL-4 75W/90

                                             CAPACITIES

Maximum load -----------------------------------------------------------------------------------------------------250kg

Fuel tank --------------------------------------------------------------------------------------------------------------- 30L

Engine oil ---------------------------------------------------------------------------------------------------------------3.8L

Gear oil ------------------------------------------------------------------------------------------------------------------2.3L

Starting ----------------------------------------------------------------------------------------------------------------≤15s

Climbing -------------------------------------------------------------------------------------------------------------- ≥25°

Battery ------------------------------------------------------------------------------------------------------------ 12V36Ah

Head Light -------------------------------------------------------------------------------------------------- 12V 35W/ 5W

Redirector Light -------------------------------------------------------------------------------------------------- 12V 5W

Tail Light -----------------------------------------------------------------------------------------------------12V 21W/ 5W

Horn---------------------------------------------------------------------------------------------------------------------12V3A

Fuse ------------------------------------------------------------------------------------------------------------------------30A

                                               SPECIFICATIONS

Brake Track ----------------------------------------------------------------------------------------------- < 7m @40 km/h

Top speed ------------------------------------------------------------------ 115km/h (or limited as customers require)

                                                 CHASSIS

Front, Rear brake ----------------------------------------------------------------- Hydraulic disc, right foot control

Front tire -------------------------------------------------------------------------------------------------------- 205/70 R15

Rear tire --------------------------------------------------------------------------------------------------------- 205/70 R15

Front Suspension --------------------------------------------------------------------------- Independent Dual A-Arm

Rear Suspension ---------------------------------------------------------------------------- Independent Suspension

Final Drive --------------------------------------------------------------------------------------------------- shaft driven

                                        TIRE PRESSURE

Front ----------------------------------------------------------------------------------------------- 280kpa2.5kg/41psi

Rear ------------------------------------------------------------------------------------------------ 280kpa2.5kg/ 41psi

                                                   WEIGHT

Net Weight ----------------------------------------------------------------------------------------------------------------689kg

G.W -------------------------------------------------------------------------------------------------------------------------780kg

Container quantity---------------------------------------------------------------------------20GP:4Units. 40HQ:12Units

Carton dimiensions---------------------------------------------------------------------------2930 mm×1770mm×850mm

1.All terrain roads like mountain,shallow lake, grassland ,snowfield,mine ,marsh ,sand ,beach,lawn etc move smoothly!

2.Maximum available colorsyou're your choice!Red ,orange ,black ,yellow,green,blue ,white,silver,camo,combination!

3.Best quality----must be---expensive?

Absolutly NO!Yes ,we can ! suitable price,better after-service!!

4.Excellent engine –Chery&CF MOTOR!Made you spend less money and own auto’s great enjoyment!

5.Relieve pressure, have great fun and enjoy lifes!please pay more attention to RENLI VEHICLE!

6.Can the conventional cars used for hunting and climbing?

our go karts/buggys can beyond your imagination,push the envelope!

7.Mixed and combined colors can be accepted!so many cool and fantastic and eyecatching originalities all designed by you!

8.Little change can be accepted !   like bumper,style,winch```

Have questions ?contact us!  anytime!anywhere,anyone!!

9.Better package to protect your karts!

Strong and fixed steel bars made the frame inside and durable carton covered outside!

10.Our go karts will be value for the money you paid !Hurry up!DO IT NOW!CONTACT US!

this Auto’s amazing power—RL 1500cc Crazy Chery 1.5L Engine,80KW,109HP,4x4,4WD,EFI,extraordinary speed—140-150km/h,93#Gasoline/Petrol/gas fueled,wonderful appearance,perfect design,innovative ideas,fantastic performance,top quality,reasonable price,better after service,driving our karts,enjoying your life!

Latest model RL 1500CC 4X4 created by Renli Vehicle!This excellent kart own fashional design,high performance,top quality, revolutionary change,an utility and multipurpose kart/buggy once drove,never forget!hi,my dear guys,hurry up!try and enjoy the great fun/racing/hunting/hiking/dune 1500cc kart/buggy!

A off road kart can match the Toyota autos at the speed of 150km/h!our dune buggy/go kart can jump from 2 meters high slope without effort!the karts are speak highly of our customers all along.we can follow clients to change sth,design,color,bumper,winch,cargo box```

we most attention to quality,wonderful /excellent appearance ,best quality and competitive price, high performance/price ratio!
