Cabin Steel Fuel Tanker Semi-Trailer - Best Price

CIMC Semi-trailer is

1) In good performance and competitive price

2) Small order is acceptable

3) Load capacity is from 20t-100t

4) Best service

5) Make according to customer request

DIMENSIONS

Tare  Weight

7200kg

Payload

31750kg

Total  Weight

38950kg

Overall  Length

13000mm

Overall  Width

2500mm

Overall  Height

2720mm

Wheel track

1840mm

Wheelbase

7280mm+1310mm+1310mm

SPECIFICATION

Main  Frame

Back three axles and steel spring balance suspension system.With steel frame throughout type and the high quality alloy steel welding longeron into h-beam

Floor

Steel Sheet 3mm thickness

Axle

Three Units of FUWA 12Ton axle

Suspension

3-axle mechanical suspension,German design

Leaf Spring

Six sets of reliable local brand, 8-piece leaf spring

King Pin

one unit of 2`` welded kingpin

Landing Gear

Two-speed ,manual operation, heavy duty JOST landing gear

Wheel Rim

Twelve units of 8.25-22.5 rim

Tyre

Twelve units of 11R22.5 tyre

Twist  Lock

Twelve nos. four nos are fasten mode,eight nos are up-down mode, of ISO twist lock for 2x20ft;1x40ft container,central locks can be laid down.

Spare Wheel Carrier

One set of spare wheel carrier including a riser.

Pneumatic Braking System

Two units of WABCO RE 4 relay valve; four units of T30/30 spring brake chamber; two units of T30 brake chamber , two units of reliable local brand 45L air tank ; two units of reliable local brand standard coppery air-connector.

Electrical  System

One unit of JAEGER POWAY ,24V 7-pin ISO 1185 socket;two sets of reliable ,local brand standard rear light,turn light,rear reflector,side light,side reflector etc. One set of  DAFA(brand ) 6-core standard Cable.

Painting

Sand blasting before painting;

one coats of primer, anti corrosion

two coat of finish painting;

colour advised by client

Accessory

One box with a set of standard trailer tool
