EEC/EPA JEEP 800cc 4WD/2WD GO KART (TKG800E-Y)

1.NEWEST ITEM.

2.4WD/2WD state avilable,

3.left/right hand drive state avilable.

4.manaul gears

5.with EEC/EPA certificate

6. alloy wheels standard

7. standard export packing by iron frame and strong carton

===================================================================================================
Type :L3 ,12valves,DOHC
Engine capacity/displacement : 800cc
Bore × Stroke : 72mmX66.5mm
Compression ratio : 9.5:1
Max out put power :39kw/6000rpm
(EEC certificate:14.9KW/6000rpm)
Max Torque :70Nm/3500--4000N.m/r/min
Ignition :Electronic multipoint injection
Fuel type : 93#(unleaded)
Lubricate oil : SAE15W-40/SF
Transmission:4-MT with reverse
Maximum load : 200Kg /Double seats
Fuel tank :23L
Starting : electric, <10s
Battery : 12V30Ah
Head Light : 12V 35W
Tail Light :12V 21W/5W
Brake Track : 7m@40km/h
Top speed :85KM/h (or limited as customers require)
Front, Rear brake : Hydraulic disc, right foot control
Front tire: AT27X8-14
Rear tire : AT27X8-14
Front Suspension :Independent Dual A-Arm
Rear Suspension : Independent Dual A-Arm
Restraint System :Dual 4-point Harness
TIRE PRESSURE
Front : 250KPa
Rear: 250KPa
DIMENSIONS
Overall Length :3130mm
Overall Width :  1565mm
Overall Height :  1510 mm
Wheel base : 2180mm
Front Track : 1360mm
Rear Track :   1360mm
Ground Clearance :  240mm
Packing:
Carton dimensions:2950X2115X815mm
N.W.:     580 (EEC 550)              kg
G.W.:     640                        kg
Conveyance:
Qty/40' HQ:         11pcs
Qty/20' GP:         4pcs
