steel good quality multistages hydraulic lifting cylinder

Specifications

The instruction for EURIK tipping gear

EURIK multistage cylinder is manufactured by the cooperation of Special Truck Company of CNHTC and NUMMI Company of Finland. Its main characteristics are stated as follows: more secure, rigid integrated limit prove inner tube take out; more efficient, high-low pressure sealing is adapting to frequent operation; more widely, adapting to different regions and different working situations; more powerful, system pressure reaches 20-24Mpa; more durable, cylinder barrel uses seamless steel pipe, chrome plated on the surface is more reliable, and all the core component are imported; more stable, supported by welded copper ring, oriented longest.

      5       TG -  F      194  X  6800  W-4

Major characteristics:

Imported high-quality steel pipe, the superior material, high strength, ensures the reliability of the product.

The inner wall of cylinder tube is thin, light weight.

New type sealing way of high pressure combined with low pressure ensures the sealing reliability under different pressure conditions, which can adapt to the requirements of different regions.

Long guide improves the cylinder’s bending resistance , and enhance the adaptability of carriage side slip.

The key components are made of press forging parts and overall performance is better , which improves the reliability of the hydraulic cylinder.

The base axis is broaden to Φ80 , more carrying capacity, stronger impact resistance,more safety.

Applying EURIK lift valve is more suitable for front lifting system.

Copper ring structure made by mechanical processing with high size precision, contacts cylinder surface evenly, and anti cornering performance is good.

Cylinder surface adopts chrome plating processing, improving the hardness, enhancing the corrosion resistance and wear resistance.

Series of cylinder is reasonable, and complete series products can meet the needs of heavy haul transportation, mine transportation and city sediment transportation,etc.

Operating system is reasonable, overall system performance is more stable.

Long-term experience in producing trucks provides technical support for the EURIK , which can meet the needs of the market.
