20mm EMT Conduits
- SHANGHAI
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Thickness | 1.07, 2.11 | Section Shape | Round | |
| Outer Diameter | 17.93 - 114.30 mm | Place of Origin | Jiangsu, China | |
| Secondary Or Not | Non-secondary | Application | Other, emt conduit | |
| Technique | Cold Rolled | Certification | UL | |
| Surface Treatment | Galvanized | Special Pipe | EMT Pipe | |
| Alloy Or Not | Non-alloy |
Product Description
The electrical metallic tubing(EMT), sometimes called thin-wall, is commonly used instead of galvanized rigid conduit(GRC), as it is less costly and lighter than GRC. EMT itself is not threaded, but can be used with threaded fittings and clamp to it. Lengths of conduit are connected to each other and to equipment with clamp-type fittings. Like GRC , EMT is more common is commerical and industrial buildings than is residential applications. EMT is generally made of coated steel.
To know how to install system, See it on youtube:
/watch?v=t5z8HC1PTag
standard | American National Standard for Steel(ANSI C80.3) |
Underweiters Laboratories Standard for Electrical Metallic Tubing(UL797) | |
National electrical code(NEC)/NFPA70 | |
Canadian electrical code(CEC)/CSA C22.1,BS7671, IEC60364. | |
Size | 1/2"-4" |
Material | 1st class steel . |
Surface Treatment | Pre-galvanized(Class3).Hot-dipped galvanized( Class 4) |
Packing | Tied by wire line or packed in woven bags. |
Applicable tolerance | Length: 10FT ±1/4inch (3050mm ±6.35mm) |
OD :1/2"~2"±0.005inch(16mm~53mm ±0.13mm) |
| EMT(Electrical Metallic Tubing) Dimensiions and Weights | ||||||||
| Nominal Diamension | Outside Diameter | Wall Thickness | Length | Weight | ||||
| Size | Size | |||||||
| Inch | mm | Inch | mm | Inch | mm | FT | mm | KG/Meter |
| 1/2" | 16 | 0.706 | 17.93 | 0.042 | 1.07 | 10 | 3050 | 0.439 |
| 3/4" | 21 | 0.922 | 23.42 | 0.049 | 1.24 | 10 | 3050 | 0.669 |
| 1" | 27 | 1.163 | 29.54 | 0.057 | 1.45 | 10 | 3050 | 0.99 |
| 1-1/4" | 35 | 1.51 | 38.35 | 0.065 | 1.65 | 10 | 3050 | 1.469 |
| 1-1/2" | 41 | 1.74 | 44.2 | 0.065 | 1.65 | 10 | 3050 | 1.698 |
| 2" | 53 | 2.197 | 55.8 | 0.065 | 1.65 | 10 | 3050 | 2.17 |
| 2-1/2" | 63 | 2.875 | 73.03 | 0.072 | 1.83 | 10 | 3050 | 3.177 |
| 3" | 78 | 3.5 | 88.9 | 0.072 | 1.83 | 10 | 3050 | 3.879 |
| 3-1/2" | 91 | 4 | 101.6 | 0.083 | 2.11 | 10 | 3050 | 5.17 |
| 4" | 103 | 4.5 | 114.3 | 0.083 | 2.11 | 10 | 3050 | 5.75 |
Related products
| Type | Labor | Weight | Material cost |
| RMC | 1.0 | 1.0 | 1.0 |
| Aluminum | 0.89 | 0.34 | 0.99 |
| IMC | 0.89 | 0.76 | 0.84 |
| EMT | 0.62 | 0.42 | 0.35 |
| PVC | 0.55 | 0.2 | 0.43 |
