3 Axles Air suspension Fuel Tank Trailer 55000L
- any port in China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
3 Axles Corrosive Material Tank Transport Semi trailer 30m3
-
3 axles Aluminum alloy chemical liquid transport semitrailer 41m3
-
CLW 3 Axis Container Skeleton Semi Trailer for 40 Feet or 20 Feet
-
CLW 3 axles Aluminum Alloy oil tanker trailer 55000L
-
CLW 3 axle Low Bed Semi Trailer 60 ton
-
56m3 LPG Storage Road Tanker Semitrailer for sale
Product Details
Type | Semi-Trailer | Material | Steel | |
Certification | Other, 3C | Size | 12990*2500*3900 | |
Max Payload | 38500 | Place of Origin | Hubei, China | |
Brand Name | CLW | Model Number | CLW9408 |
Product Description
3 Axles Air suspension Fuel Tank Trailer 55000L
Air suspension Fuel Tank Trailer is also called cargo semitrailer ,mobile transport truck,tanker truck semitrailer,etc, widely used in transporting and discharging gasline, diesel and other fuel product. We can supply tanker ranged from 4000L to 45000L,Tanker Semitrailer ranged from 30000L to 6000L. Experience of ten years of manufacturing pressure vessel ensure reliable quality. Use this type of semitrailer can improve transport efficiency 30-50%, reduce cost 30% -40%, reduce fuel consumption 20%- 30%.
Main Parameter of 3 Axles Air suspension Fuel Tank Trailer 55000L
Whole truck main technical parameter | |||
Product Model | CLW Air suspension Fuel Tank Trailer | Overall Dimension(L*W*H)(mm) | 12990×2500×3900 |
Tank Volume(L) | 55000 | Tank Dimension(mm) | Front-end(3100×2500×1900) rear-end(8600×2500×2150) |
Front/ rear suspension(mm) | -/1870 | Approach/ departure angle (° ) | -/16 |
Curb weight(kg) | 7170 | suspensionType: | Air suspension or leaf Spring |
Axle number | 3 | Front/Rear axle load(Kg) | -/39000 (three FUWA axis combined) |
Wheelbase(mm) | 7200+1310+1310 | Rear tread(mm) | 1840/1840/1840 |
Tire size | 11.00R20 12PR or 425/65R22.5 | Number of Tire: | 12 |
Superstructure parameter | 1. Tank material: 5mm carbon steel, 90# King pin ,28ton hydraulic support legs , optional Aluminum Alloy or stainless steel tank | ||
2. Equipped with 2 oil pipe, gravity valve,one ladder | |||
3. Equipped with several tool boxes, two fire extinguisher, ground wire | |||
4. Tank can be separated to several unattached small storehouse to fill different fuels, also optional equipped with oil pump | |||
Warranty | 12 months, from the date of supply |
This Air suspension Fuel Tank Trailer show as the following:
Large water tank of this Air suspension Fuel Tank Trailer:
Tool Box of this Air suspension Fuel Tank Trailer :
Air suspension of this Air suspension Fuel Tank Trailer :
FUWA 13ton Axle of this Air suspension Fuel Tank Trailer :
TFOC 28ton Manual outrigger of this Air suspension Fuel Tank Trailer :
Brief Introduction of Company:
Hubei ChengLi Special Automobile Co., Ltd ,which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. It has registered trademark"CHENLIWEI" and the products code is CLW. It has solid technology,flawless inspection,advanced equipments,reliant quality and flexible modes of operation. What's more, it has roundly passed the certificaton of ISO 9001-2008 and the 3C Certification(China Compulsory Certification) and other certifications that export needed.
Since ChengLi company was established in Sep. 2004, ChengLi Special Trucks have always taken the top place in Chinese market in recent ten years and have procured remarkable achievements interiorly and oversea.
We can design and produce many kinds of special trucks accurately as your request. Our company own independent export right, and has a mount of clients overseas, such as the U.N., Sudan, Nigeria, North America, West Africa, Congo, Vietnam Ghana, Kazakhstan etc. We strives for the survival by the quality and credit standing is the guarantee of our success.
ChengLi Special Automobile co.,Ltd is located in Suizhou City, the native place of YanDi ShenNong,the hometown of BianZhong and the City of Special Truck. Welcome the friends from all over the world to SuiZhou! You will be the most enthusiastic reception.
Our certificates;
Production Equipments:
Oil tank Semi Trailer series:
