fecal tanker truck with 5m3

FOB Price

USD $16,600 - $19,700 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

fecal tanker truck with 5m3
Fecal capacity 8000L
Fecal suction lift =>6m
Fecal tank 3600*1900*1200
Yuchai engine

Fecal suction truck

Fecal Suction Truck:

mainly used for cleaning urban and rural public convenience. Suction-type is best.

To improve human living environment, fecal suction truck can reduce secondary pollution in urban and rural.

We can produce all kind of different tonnage of , we have light, medium and large capacity hopper of suction truck.

According to your needs, choosing the fecal suction truck which one is your want to buy.

Item	unit	parameter
Vehicle model		CLW 5090GXE3 Fecal suction truck
Chassis model
Horse Power	hp	180
Overall dimensions	mm	7890×2470×3080
Fact cubage	L	10500
GVW	kg	Approx 14490
Rated loading capacity		Approx 7000
Mass in working order		Approx 7295
Body internal dimensions	mm	5000×2200×1350
Wheel base		4500
F/R track base		1940/1860
Approach/departure angle	°	34/18
Exhaust/hp	ml/hp	5880/180
Max speed	km/h	90
Tire specification	10.00-20	Engine type	EQB180-20
Traction system	4*2	transmission	6-speed with over drive
Number of axles	2	Electric system	24v
Operation control system	Electrically hydraulic control	Allowable passengers in cab	3
Equipment	Equipped with vacuum pump(rating rotate speed=1400r/m, min rotate speed800r/m, max suction lift6m, vacuum500mmHg, clockwise) Equipped with power take off, transmission shaft, fecal tank, pipe network, fecal pipe for observing and cleanout equipment Time for full suction5min Cabin with a bed. Strong engine, high-speed.
Engine	DONGFENG Cummins, diesel engine.
Production cycle	5-7 days
Warranty	12 month, from the date of supply

fecal suction truck , sewage suction truck , suction truck. fecal suction truck with 6M3. suction tanker truck. fecal tanker truck
