HSH Series Type for Construction Express Mini Lifting Chain Lever Hoist
- QINGDAO
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | JNDO | Model Number | HSH | |
| Usage | Construction Hoist | Power Source | Lever | |
| Sling Type | Chain | Maximum Lifting Weight | 9T | |
| Maximum Lifting Height | 6M | Lift Speed | by your change | |
| Certification | CE,GS,ISO | Warranty | 1 year | |
| After-sales Service Provided | No overseas service provided |
Product Description
HSH series type for construction alibaba express mini lifting chain lever hoist
HSH series manual lever hoist Description:
HSH series lever block is one kind of high efficiency multipurpose manual hoisting machinery, but widely applies in shipbuilding, electricity, mines, construction sites, transports, post and telecommunication for installing equipment, lifting goods, pulling mechanical parts etc. It has exceptional advantages particularly for pulling in every limited narrow place, in the upper air high above the ground and at any angle.
1.Lever block is a kind of manual hoisting appliance which is highly efficient and versable .It especially has the unique superority when used in the narrow places ,the open air, aloft work and all kinds of different angles of traction.
2.Safe ,reliable ,and durable .
3.Excellent performance ,easy o operate and convenient maintence .
4.Smal volume ,light weight and portable in size.
5.High efficiency ,fast lifting speed and light pulling force.
6.Advanced structure and attractive appearance.
HSH series manual lever hoist Parameter:
Model | HSH-0.25A | HSH-0.5A | HSH-0.75A | HSH-1.5A | HSH-3A | HSH-6A | HSH-9A |
Capacity load T | 0.25 | 0.5 | 0.75 | 1.5 | 3 | 6 | 9 |
Standardlift M | 1 | 1 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
Test load T | 0.375 | 0.75 | 1.125 | 2.25 | 3.75 | 7.5 | 11.25 |
Effort to rated capacity N | 160 | 240 | 280 | 310 | 320 | 340 | 360 |
No.of load chain | 1 | 1 | 1 | 1 | 1 | 2 | 3 |
Diameter of load chain MM | 4 | 5 | 6 | 8 | 10 | 10 | 10 |
Min.distance between hooks MM | 160 | 280 | 320 | 380 | 480 | 600 | 700 |
Net weight KGS | 3.6 | 6.5 | 7.8 | 12 | 21 | 32 | 48 |
Extra weight per metre of extra lift KGS | 0.3 | 0.5 | 0.8 | 1.4 | 2.2 | 4.4 | 6.6 |
lever hoist lever block Precaution:
1.Overload ,extending the handle and stamping onhtehandle with foot are strictly forbidden.
2.Before using ,inspect the hooks upperand lower to checkwhether they are firm.The load should be attached on the center of the hook,the incorrect loading is strictly forbidden.
3.When used in tightening goods in transport ,the lever hoist should be parallel to the bound items,and provent the chain from sharp edge or comer.
4.Rough operation is strictly forbidden ,don't expose the lever hoistin rain or very humid places.
5.It's strictly frobidden to use when the chain is twisted.The hook should be replaced when the verrical angle of top and bottom hook is above 10.
HSH series manual lever hoist Details:

We can provide not only amazing products,but also special ones designed at requests.We'll do our best to meet the need of customers.
