Product Details
| Place of Origin | Shandong, China | Brand Name | JNDO | |
| Model Number | MHC | Type | Hydraulic Jack | |
| Certification | CE GS SGS | Min Height | 18MM | |
| Max Height | 180MM | Capacity (Load) | 11-20T |
Product Description
small lifting jacks small hydraulic jack
Hydraulic jack
1This series products have 5 specification ,MHC-2.5RS ,MHC-5RS ,MHC-15RS ,MHC -25RS .Widely used in machinery equipment, bridge construction, railway track of installation and maintenance, and transportation of heavy loading and unloading , automobile tractor repair,ect.
2 This series product is made of high quality steel, after heat treatment and welding, structure simple, easy operate , durable, high quality is stable, safe and reliable; Top and hook lifting combination, easy to low position operation, is a kind of widely used lifting tool.
3, This series product operating handle design for 180 degrees of rotation, according to different places, thus changing the Angle is more convenient to use.
4, Use the machine please pay attention to the follows .
a, The machine should put on a flat place when using , and avoid deflection .
b, It is strictly prohibit the lifting height more than the product requirement limit , or else leading to the Guide fall off from the machine.
C, Forbid the overload operation .
d, Don’t put your finger and feet below the object when using .
5,Before using keep the Guide lubrication ,keep the machine clean ,after use pay attention to put lightly ,not collision and arbitrary throws, if the bad thing occurs it will leading to damage and oil circuit malfunction .
hydraulic jack Main Parameter
Model | Overall size (mm)
| Hook Mini height (mm) | Lifting height (mm) | Rated capacity (T) | Weight (kg) | |
TOP | HOOK | |||||
MHC-2.5RS | 210X140X232 | 16 | 115 | 5 | 2.5 | 11 |
MHC-5RS | 260X200X283 | 20 | 148 | 10 | 5 | 24 |
MHC-10RS | 295X220X322 | 25 | 158 | 20 | 10 | 36 |
MHC-15RS | 305X255X350 | 30 | 158 | 30 | 15 | 55 |
MHC-25RS | 340X285X350 | 50 | 158 | 50 | 25 | 75 |
To ensure that customers use our Jack with no worries, hereby we warrant:
1. We strictly select good material to ensure the reliable quality.
2. Not only in the selection of materials, but also in every production procedures, we strictly act according to the ISO9001 standard, and control by full-scale inspection.
3. The Technical and specialized support from us will be available.
4. The upgraded products information will be timely supplied.
We can provide not only amazing products,but also special ones designed at requests.We'll do our best to meet the need of customers.
