SC Standard Airtac Pneumatic Cylinder for Tyre Vulcanizing Machine

FOB Price

US$ 50 - 1,000 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Cylinder		Place of Origin	Guangdong, China
Model Number	SC		Brand Name	raypoo

SC standard airtac pneumatic cylinder for tyre vulcanizing machine

1.Standard cylinder manufactured by our enterprise;

2.The seal of piston adopts heterogeneous two way seal structure.Its dimension is tight and it has the function of oil reservation;

3.It is tie rod cylinder.The cylinder barrel and front/rear cap is jointed by tie rods with high reliability.

4.Compared with ISO15552 standard cylinder,SC series cylinder with the same bore size.

Example	SC	50	50	20	S	*	*	P
Meaings	Model	Bore size	Stroke	Ajustable stroke	Magnet	Seals material	Mounting type	Thread
Explain	SC:double acting type	No this code	No this code	10:10mm 20:20mm 30:30mm 40:40mm 50:50mm 75:75mm 100:100mm	S:with magnet Blank:without magnet	Blank:TPU H:Viton N:NBR	LB FA FB CA CB TC	P:PT T:NPT G:G
	SCD:double rod type
	SCJ: adjustable stroke type

Bore size		32	40	50	63	80	100
Acting type		Double acting
Fluid		Air ( to be filtered by 40um filter element)
Mounting type	SC	Basic FA FB CA CB LB TC TF
	SCD,SCJ	Basic FA LB TC TF
Operating pressure		0.10~1.0Mpa (15~145Psi)(1.0~10.0 bar)
Proof pressure		1.5Mpa (215psi)(15 bar)
Temperature °C		-20~80
Speed range mm/s		30~800
Stroke tolerance		0~250 251~1000 1001~1500
Cushion type		Variable cushion
Adjustable cushion stroke (mm)		21				28	29
Port size		1/8”	1/4”		3/8”		1/2”
*PU tube size(ODID)**		Φ8*φ5				Φ10*φ6.5

Packaging & Shipping

How are orders packed and shipped?

Depends on customers' orders. All goods are packed with a plastic bag with an outer carton and a wooden pallet( fumigation).

Can be customized according to customer requirements

Our Services

We provide hydraulic, lubrication, pneumatic technology consulting, system design, and the parts.

Could Raypoo offer OEM service?

Yes. Raypo is able to offer OEM with customers' brand name and trademark onto the product.

Do Raypoo products come with a warranty?

Yes.Raypoo offer 1-year guarantee without abusive usage on all purchases which begins with the bill of lading.
