Advanced Sanshon fruit vacuum freeze dryer ( lyophilizer)
- Ningbo
- T/T Credit Card
You May Like
Product Details
Place of Origin | Zhejiang, China | Brand Name | sanshon | |
Model Number | FDG | Type | Other, Food freeze drying | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Advanced Sanshon fruit vacuum freeze dryer ( lyophilizer)
Vacuum freeze dehydrator,Working principle,
After some pretreatments, put the foodstuff in a low temperature and vacuum surroundings, the inner moisture of the foodstuff will sublimate from solid state to gaseous state so that the foodstuff is dried.
Applicable range,
Fruit, vegetable, aquatic, meat, instant foodstuff, chemical stoneware ect
The whole equipment includes the following devices,
1. pretreatment system
2. freezing and drying tank
3. heating system
4. vacuum system
5. refrigeration system
6. material conveyor
7. control system
Advantage of vacuum freeze drying:
1. The thermal sensitive material could also be rather completely dehydrated under this vacuum freeze drying method. Medical dried with this method could be very steady and stored longer.
2. Compared with other drying method, materials are all dried in a frozen state with vacuum freeze drying method and there’s little change in physical structure and molecular structure. The organization structure and appearance could be kept.
3. There would be no hardening with the appearance and its inner would form like sponge with many holes under this kind of drying. Thus it’s of great re-hydration property and could regain its state of fresh in a short period of time.
Application, vacuum freeze dryer
Fruit, vegetable, aquatic, meat, instant foodstuff, chemical stoneware ect.
Parameters | Model | FDG-0.5 | FDG-10 | FDG-20 | FDG-50 | FDG-100 | FDG-180 | FDG-200 | FDG-280 |
Drying area (m2) | 0.5 | 10 | 20 | 50 | 100 | 175 | 200 | 275 | |
Mean dehydrating amount (kg/h) | 0.6 | 12 | 20 | 50 | 100 | 175 | 200 | 275 | |
Size of material tray (m) | 310×540×30 | 745×635×30 | 435×555×30 | 540×635×30 | |||||
Number of material tray (pcs) | 3 | 21 | 80 | 144 | 288 | 504 | 576 | 792 | |
Size of pot (M) | 1.5×1.6×1.6 | φ1.4×2.1 | φ1.8×2.4 | φ2.4×4.8 | φ2.4×8.9 | φ2.4×14.8 | φ2.4×16.6 | φ2.4×21.9 | |
Operation vacuum (pa) | 13.3~200 | 26.6~200 | |||||||
Heating plate T (°C) | Normal temperature~+120°C | ||||||||
Electric heating (Kw) | 2 | 21 | 40 | ||||||
Steam consumption (Kg/h 0.7Mpa) | 140 | 270 | 470 | 540 | 750 | ||||
Cold load consumption (Kw) | 1.5 | 21.6 | 36 | 90 | 180 | 310 | 360 | 490 | |
Installed power (Kw) | 6.5 | 55.8 | 104.5 | 41.2 | 69.7 | 102.5 | 117.5 | 125.5 |
Zhejiang Sanshon Machinery Manufacturing Co., Ltd was founded in 1993, located in the most convenient transportation and prosperous economy of Yangtze River delta Shangyu city, Zhejiang. Zhejiang Sanshon Machinery Manufacturing Co., Ltd adjacent to the beauty of the CaoE river, and in less than 5 KM there are three expressways, they are Hangzhou-Ningbo (G92), Changshu-Taizhou (G15w), and 104 national road line , the HangYong high speed railway. Moreover it is less than 100 KM to Hangzhou and Ningbo airport.
It is specialized in manufacturing food processing machinery, which includes fruit & vegetable hot air drying(AD), quick freezing (IQF), vacuum freeze dryer(FD). The company passed ISO9001:2000 quality standard under the efforts of all employees. There are three equipments has been assessed as National New Product. And in 2007, Sanshon was recognized for New and High Technical enterprise in Zhejiang Province.
The company not only in r&d and manufacturing ,but also enjoy the right of import and export. And the machinery from Sanshon has been exported to more than 10 countries, including Vietnam, Thailand, Uzbekistan, Azerbaijan, Iran, Mexico, Venezuela, Peru, Australia, Cyprus, Libya, etc.
Based on more than 20 years’ experience in food process machinery manufacturing, later it established Shaoxing Sanshon Steel Co., Ltd () and Shundi foods Co., Ltd()in Zhejiang and Shanghai. Sanshon now is capable of providing integrated services, including product consultation, design, workshop establishment, equipment manufacturing and installation, training of machine operation in the field of vacuum freeze drying machine (FD), hot air drying (AD) as well as quick frozen (IQF) machines.
Sanshon is well prepared to be a pioneer in the field of dehydration, quick frozen, vacuum freeze drying to contribute to food processing industry!
Term,Conditions
Ordering Information
Payment:
We usually accept T/T,L/C, please send email to negotiate payment term if you can not accept T/T or L/C.
Packing:
Iron framework with external plywood and seaworthy package.
Please send email for the extra cost of different packing.
Delivery Time:
Different products will spend different production period: from 30-120 days after 50% advanced payment.
For urgent order, Could be faster, please send email to negotiate.
How to make an order?
1.Client make 50% deposit or open LC after receiving our PI.
2.Client approve our equipment.
Arrange shipment
1.Client effect balance payment before shipment.
2.Supplier send original documents or telex release the goods.
3.Quality warranty for 1 year after shipment.
