Industrial Air Cooled Water Water Cool Chiller

 Air water chiller including water pump and water tank. Client can choose with or without water pump and water tank.Compressor: Hitachi, Daikin, Danfoss, Copeland, client can choose the compressor Water cooled  type: condenser and evaporator use Shell-and-tube. Air cooled type: Shell-and-tube condenser, finned type evaporator.

Besides the features of tank water-cooled machine set, air blast cooling chiller does not need extra cooling water tower and is easy to install and operate so that it is suitable for small production equipments.
Phase reversion protection, Phase lack protection, overload current protection ,discharge air temp. protection, low &high pressure protection.

1. Power source phase deficient protection;
2. Circuit breaker;
3. Compressor  over load protecting and indicating lamp;
4. Pump reversal protecting and indicating lamp;
5. Pump over load protecting and indicating lamp;
6. Cooling water bad heat loose protecting and indicating lamp;
7. Ice water freeze protecting and indicating lamp;
8. Coolant lose protecting and indicating lamp;
9. Safety valve abnormal by coolant high presure;
10. Ice water by-pass circuit leakage;
11. The temperature deviation alarm and the indication;
12. Ice water outlet pressure gauge;
13. Coolant high pressure gauge;
14. Coolant low pressure gauge;
15. Break down alarm buzzer;

Injection Industry

Golden chiller can accurately control the temperature of mold which can improve the quality and production rate.

Electronic Component Industry

Golden chiller can stabilize the molecular structure of electronic component inside. This can improve the FTQ and product time.

Machinery Industry

Golden chiller can cool down the oil for the machine and stabilize the oil temperature and pressure. It’ll extend the useful life of oil. And it can also improve mechanical lubrication efficiency.

Electroplating Industry

The temperature of electroplate can be controlled by our chiller. It can improve the density and smooth of electroplate and production efficiency.

Food & Drink Processing Industry

The temperature of processed food and drink will be too high to be packaged. Golden chiller can cool it down through food grade stainless steel heat exchanger.

Air conditioner system

Widely used in building air conditioning system, small and medium-sized office, workshop, restaurants, villas and other air conditioning environment
