Home > Products > Plastic Belt-type Color sorter > plastic color sorter machien Video-MINGDER

plastic color sorter machien Video-MINGDER

FOB Price

US$ 60,000 - 80,000 / Set

1 Set(Min. Order)

Port SHANGHAI
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Brand Name	MINGDER
Model Number	MS-LD640/MS-LD1280	Dimension(LWH)	331015802645
Certification	ISO 9001 CE	Warranty	One Year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Quick information- Plastic flaeks/granules CCD belt-type Color Sorting Machine

1. Belt-type soft conveying system

2. High flexibility, appliable to a wider range of materials.

3. Various sorting mode and automatic memory function

4. Double-layer belt system, high impurity

5. Leading LED light source technology

6. The world' s top 2048 CCD sensor

7. Leading intelligent shape function

8. Optional NIR function

Technical Features

1.High speed and productive conveying system, belt-type soft conveying system has lower drop, low broken rate, applicable to more various materials.

2.High flexibility, applicable to a wider range of materials, can accurately set the operation parameters according to the moving track of specific materials; which makes the machine multifunctional and high value-added.

3.Powerful Operation System, various sorting mode and automatic memory function, set sorting system once for repeated materials, best sorting results are acquired easily.

4.Double-layer belt-type system, for materials with high impurity for example plastic. It can complete sorting in one time.

5.Resorting function is available, it can re-sort ready to go material and waste material, can achieve higher color sorting accuracy.

6.Leading LED light source technology. High efficiency, long service life,strong anti-interference ability and lower cost.

7.The world’ s top 2048 CCD sensor has high resolution to detect various materials.

8.Leading intelligent shape function, can effectively detect different size and shapes.

9.Optical NIR function can detect and remove various malignant impurities.

Technical parameters

Model	MS-LD640	MS-LD1280
Width(mm)	640	1280
Capacity(T/H)	≤3	≤5
Sorting accuracy(%)	≥99	≥99
Optimized carryover	≥10:1	≥10:1
Power supply	AC220V 50HZ	AC220V 50HZ
Power(kW)	2.7	3.5
Air Pressure(Mpa)	0.6~0.8	0.6~0.8
Weight(Kg)	900	1200
Dimension(L×W×H:mm)	3310×900×2345	3310×1580×2645

Note: The above data is worked out base on broad bean with 3% impurity, it may vary according to different materials and different impurities percentage etc.

Sorting Cases

Our Services

1.Free installation and commissioning
2.Free maintenance for one year
3.Set office overseas and online operation instruction & solution within 24 h
4.Long life free upgrading software.

Contact us:

Diana Hong

Skype: dianahongsmile

Email: dianahong @

Whatsapp: 008613966725592

Wechat: h624350311

Packaging & Shipping

FAQ

Q:Do you have warranty for our equipment?

A: YES. We provide life-long time maintaining service.

Q:What's the lead time ?

A:about 10-20 working days.

Q: How do you ensure the quality of your products?

A: Generally, our equipment are the most durable type in the industry, this is also the feature of the label impression of Mingder for most of our customers at home or abroad. With our experienced quality control team, we are trying to offer most of our customers the product with best quality.

As the professional manufacturer of ore or stone sorting equipment, we are pleased to offer you the best product in a competitive price.

Quotation of other sorting equipment is also available, please feel free to contact us if you have any request.

Devotion makes profession, professional so excellence!
