Home > Products > pump & ram > 150t TL1410-1 flat oil cylinder
150t TL1410-1 flat oil cylinder
Negotiable
/ Piece
10 Pieces(Min.Order)
- 10000 Piece / Pieces per Month
- SHANGHAI
- T/T
You May Like
Product Details
| Standard or Nonstandard | Standard | Structure | General Cylinder | |
| Power | Hydraulic | Body Material | Steel | |
| Maximum Stroke | xx | Shaft Diameter | xx | |
| Place of Origin | Zhejiang, China | Model Number | TL1410-1 | |
| Brand Name | TONGLI,OEM |
Product Description
Specifications
150t TL1410-1 used flat oil cylinderHard coat finish on all surfaces resists damage and extends cylinder life.
Steel base plate and saddle of protection against l
150t TL1410-1 used flat oil cylinder 150t TL1410-1 used flat oil cylinder
| Model | Capacity | Stroke | Cylinder Body Height | Working Pressure | Single Weight |
| (ton) | (mm) | (mm) | (Mpa) | (kg) | |
| TL1401-1 | 2 | 6/3 | 31/38 | 48 | 0.5/0.55 |
| TL1402-1 | 4 | 6/14 | 33/41 | 46 | 0.6/0.7 |
| TL1403-1 | 5 | 6/14 | 33/41 | 57 | 0.65/0.8 |
| TL1404-1 | 10 | 11 | 44 | 62.9 | 1.2 |
| TL1405-1 | 20 | 11 | 52 | 70.8 | 2.5 |
| TL1406-1 | 30 | 12 | 60 | 67.9 | 4.2 |
| TL1407-1 | 50 | 12 | 66 | 77 | 7 |
| TL1408-1 | 75 | 12 | 79 | 71 | 12 |
| TL1409-1 | 100 | 12 | 85 | 74 | 15 |
| TL1410-1 | 150 | 11 | 99 | 73 | 27 |
