portable rice milling machine
- FOB Shanghai
- T/T D/P D/A Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Anhui, China | |
| Brand Name | JIETAIZHINENG | Model Number | JTDM-CCDR4 | |
| Production Capacity | 4-11T/H | Voltage | 220V,50HZ | |
| Power(W) | 1200-3000w | Weight | 1100kgs | |
| Dimension(L*W*H) | 1983*1520*1800mm | Certification | CE,ISO | |
| Warranty | One year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
1.Widely chute , positioned each channel matched one vale correctly ,ejecting the discolor one to the defect chamber, and good materials slide down into the finished chamber .
2. The hardware system architecture of chip is ARM+FPGA, become the super brain of color sorter to operate
the program data.
3. Cutting-edge double row LED light source equipment with cooling system is more
Stable and long service life.
4. The operation interface adopts the 10-inch TFT color touch screen with multi-language, you can change the language the easily.
5.You operate the machine just only by the program setting of the compute,not by hands it
is easy to operate.
6.Japan TOSHIBA brand CCD sensor is top quality and excellent ability to treat the image.
We are the first to apply true color of three primary colors on CCD. It can identify tiny spots smaller than 0.02 mm2.
Applications:
Applicable to all types of materials,rice, grain,and industrial granules etc.
Model | JTDM-CCDR2 | JTDM-CCDR3 | JTDM-CCDR4 | JTDM-CCDR5 | JTDM-CCDR6 |
Throughput(T/H) | 1.5~3 | 3~8 | 4~11 | 6~13 | 7~15 |
Channels | 160 | 240 | 320 | 400 | 480 |
Chutes | 2 | 3 | 4 | 5 | 6 |
Light Source | Led Light | Led Light | Led Light | Led Light | Led Light |
Pixel of Camera | 2048 | 2048 | 2048 | 2048 | 2048 |
Color Sorting Accuracy | ≥99.99% | ≥99.99% | ≥99.99% | ≥99.99% | ≥99.99% |
Carryover rate | ≥10:1 | ≥10:1 | ≥10:1 | ≥10:1 | ≥10:1 |
Power(KW) | 0.8-2 | 1.0~2.5 | 1.2~3.0 | 1.4~3.5 | 1.6~4.0 |
Air pressure(Mpa) | ≥0.6 | ≥0.6 | ≥0.6 | ≥0.6 | ≥0.6 |
Voltage(v) | 220V/50HZ | 220V/50HZ | 220V/50HZ | 220V/50HZ | 220V/50HZ |
Air consumption (L/min) | 800-1300 | 1000-1800 | 1200-2500 | 1500-3000 | 1800-3600 |
Weight(kg) | 700 | 900 | 1100 | 1300 | 1500 |
Diamension(mm)L*W*H | 1674* 1520*1800 | 1674* 1520*1800 | 1983*1520*1800 | 2319*1520*1800 | 2655*1520*1800 |
Package | wooden case | wooden case | wooden case | wooden case | wooden case |
Note : The above impurities is around 2% . The Specific parameters will be different based on the raw material and impurities
Packing Size: 2200*1720*2100mm
Container Load: 2pcs/20FT or add 1 pc air compressor; 4pcs/40GP or add 1 set air compressor
Outer Packing: standard wooden case with protective film inside.
Anhui Jietai Intelligent Technology Co.,Ltd originated from Thailand in southeast Asia with 20 years experience
Pass the ISO9001 and international certificate as CE
Provide OEM and ODM service to overseas customer
Export to over 10 countries in Southeast Asia, Africa, Middle East and area etc.
Set up headoffice in Thailand
24hour online service
one year warranty
power service team in Thailand
Q1:Can I add my logo on the machine?
A:Yes,OEM and ODM are available for us.
But you should send us the Trademark authorization letter.
Q2:How can i get the after-service?
A:We will arrange engineer to install the machine when you perpare for the equipment platform.
and we have power service team in Thailand southeast
Q3:Do you have inspection procedures for machine?
A:100% self-inspection and test before packing
Q4: Could you supply the accessory equipment ?
A:Yes,we will supply from cooperate factory if you need.
Q5:Can I have a visit to your factory before the order?
A: Sure,welcome to visit our factory.
Here is our factory address:Hefei City,Anhui Province,China.
Our factory is near Shanghai, Suzhou City,We can pick you up in the airport or railway station.
Hotel booking service is available.
