Product Details
Condition | New | Type | Ball Mill | |
Motor Type | AC Motor | Power(W) | 18.5-260KW | |
Capacity(t/h) | 1-30T/H | Place of Origin | Henan, China | |
Brand Name | YIGONG | Model Number | Diameter by length | |
Dimension(L*W*H) | many sizes | Weight | 5-150T | |
Certification | ISO,BV,SGS | Warranty | 1 year | |
After-sales Service Provided | Engineers available to service machinery overseas |
ball mill packed in normal container,small parts in carton or bags.
Product Description
Hot Sale Energy-Saving Ball Mill from Yigong
Ball mill is mainly used for grinding materials in such production industries as cement, silicate product, new building materials, corhart, chemical engineering, nonferrous and black metal, mineral processing, glass and ceramic, etc.
It is used for grinding various ore and other grindable materials dry or wet.
Structure of Energy saving paint ball mill from YIGONG machinery
Ball mill mainly consists of feeding part, discharging part, gyre part, transmission part (decelerated machine, small transmission gear, motor, electric control) and so on.
The hollow axis adopts cast steel, the lining plate can be replaced, the big gyre gear is made of forging rolling gear, and there is lining plate in the cylinder body, which has favorable abrasion resistance.
Working Principle of Energy saving paint ball mill from YIGONG machinery
The ball mill is a horizontal rotating device transmitted by the outer gear.
The materials are transferred to the grinding chamber through the quill shaft uniformly.
There are ladder liner and ripple liner and different specifications of steel balls in the chamber.
The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.
Ball Mill Technical Data
Model | Speed of bucket(r/min) | Weight of ball(t) | Size of feed opening(mm) | size of outputting feed(mm) | Production(t/h) | Power(Kw) | Weight(t) |
900*1800 | 38 | 1.5 | 20 | 0.075-0.89 | 0.65-2 | 18.5 | 3.6 |
900*3000 | 38 | 2.7 | 20 | 0.075-0.89 | 1.1-3.5 | 22 | 4.5 |
1200*2400 | 32 | 3.8 | 25 | 0.075-0.6 | 1.5-4.8 | 45 | 11.5 |
1200*3000 | 32 | 5 | 25 | 0.075-0.4 | 1.6-5 | 45 | 12.8 |
1200*4500 | 32 | 7 | 25 | 0.075-0.4 | 1.6-5.8 | 55 | 13.8 |
1500*3000 | 27 | 8 | 25 | 0.075-0.4 | 2-5 | 90 | 17 |
1500*4500 | 27 | 14 | 25 | 0.075-0.4 | 3-6 | 110 | 21 |
1500*5700 | 27 | 15 | 25 | 0.075-0.4 | 3.5-6 | 132 | 24.7 |
1830*3000 | 24 | 11 | 25 | 0.075-0.4 | 4-10 | 180 | 28 |
1830*6400 | 24 | 23 | 25 | 0.075-0.4 | 6.5-15 | 210 | 34 |
1830*87000 | 24 | 25 | 25 | 0.075-0.4 | 7.5-17 | 245 | 36 |
2200*5500 | 21 | 30 | 25 | 0.075-0.4 | 10-22 | 370 | 48.5 |
2200*6500 | 21 | 30 | 25 | 0.075-0.4 | 14-26 | 280 | 52.8 |
2200*7500 | 21 | 33 | 25 | 0.075-0.4 | 16-29 | 475 | 56 |
2200*9500 | 21 | 38 | 25 | 0.074-0.4 | 18-35 | 475 | 62 |
Pictures of Energy saving paint ball mill from YIGONG machinery
Rubber liner of Ball Mill
Ball Mill two stages
Ball Mill head
ball mill machine with the best price and always good quality for Chinese customer and some nearby countries
loading containor..
ball mill machine with the best price and always good quality ,we have many kinds of certifications.
Certification ISO9001
ball mill machine with the best price and always good quality
What is the material would you like to mill?
What is the input size and output size ??
Capacity?
