24V 12V buck switch turn 12V 36V 48V car power converter switch 12V2A DC-DC step-down module

Product Name: 24V 12V buck switch turn 12V 36V 48V car power converter switch 12V2A DC-DC step-down module
Product Type: KREE-1555-12-24W
Color classification:
Product details: The parameter table
 Input voltage: (DC15V-55V between)
 Output voltage: DC12V
 Output Current: 2A
 Output Power: 24W
 Conversion efficiency: up to 96% of the output ripple: 50mV (MAX)
 Operating temperature: Industrial grade (-40 ℃ to + 85 ℃)
 Volume: 46 * 32 * 18mm
 Weight: 53 g

 Features

1. Imported integrated switching regulator module manufacturing.

2. synchronous rectification, the conversion rate of 96% or more, very low heat.

3. reverse polarity protection, over-voltage, over-current, over-temperature, short circuit protection automatic braking function, and work in the conditions of recovery.

4. epoxy potting, waterproof, shock, moisture and dust.

5. The line length is about 15CM, slim, small size, easy installation.

6. Connection: Enter the red (+) black line (-), the output of the yellow line (+) black (-).

7. Scope: bus, CMB, large trucks, motor car, solar power, bus display, taxi advertising screen, absolute taxi radio without interference, car audio, LCD TVs, LED, intercom and monitoring systems .
