Home > Products > Lab magnetic separator > Laboratory Magnetic Tube/ Laboratory Magnetic Separator Equipment
Laboratory Magnetic Tube/ Laboratory Magnetic Separator Equipment
- Shanghai
- T/T
You May Like
-
Small Magnetic Ore Separator / Small Size Magnetic Ore Separator
-
Laboratory Gold Mining Lab Magnetic Tube
-
Drum Type Ore Wet XCRS Series With ISO9001:2OO8/small Size Magnetic Separator
-
Mining Magnetic Separator/laboratory Drum Wet Low-intensity Magnetic Separator
-
Asy Operation/high Intensity Magnetic Separator/ Iron Magnetic Separator
-
XCRS Series Low-intensity Drum Wet Permanent Magnetic Separator
Product Details
| Condition | New | Type | Magnetic Separator | |
| Place of Origin | Jiangxi, China | Brand Name | oasis | |
| Model Number | XCGQ 50 | Voltage | 50 HZ | |
| Power(W) | 220 V | Dimension(L*W*H) | 1000/800/500 | |
| Weight | 200 kg | Certification | ISO9001:2008 | |
| Warranty | One year | After-sales Service Provided | Overseas service center available |
Product Description
XCG(Q)S 50 Magnetic Tube or Davis Analyzing Tube is applicable in labs. of mine, metallurgical, geological and other industries. It is designed to determine magnetic content in strong magnertic mineral in the mineral processing operation. The product is produced by the only enterprise designated by the former Ministry of Geology and Mineral Mineral Resources, in compliance with the Industrial standards
Magnetic Tube is C Type electromagnet fitted with glass tube between pole ends to reciprocately move and swing.When the test materials to be separated pass therough magneric fields.the magnetic portion will be absorbed near the tube walls and the non-magneric portion will be washed down by water in the mechanical movement and discharged.. The product is produced by the only enterprise designated by the former Ministry of Geology and Mineral Mineral Resources,in compliance with the Industrial standards
Model | Uite | XCGQ 50 |
Tube Dia | mm | 50 |
Vibrating Freq | r/min | 70 |
magnetic gap | mm | 52 |
Feed size | mm | 0.5 |
Intensity | GS | 2500(200KA/m) adjustable |
Voltage | V | 50HZ 220AC |
Exciting power | VA | 500 |
Supply equipment | taiwan | Field power supply 1set |
Overall dimensions | mm | 1000/800/500 |
Weight | kg | 200 |
