Home > Products > New Products > Made in China Freshment Assurance Generator Set for Reefer Container Underslung
Made in China Freshment Assurance Generator Set for Reefer Container Underslung
- DALIAN TIANJIN QINGDAO
- T/T
You May Like
-
Three Phase 16kw Reefer Clip on Genset Carrier for Transportation
-
Doosan Power Plant 1 Year Warranty 50Hz Ats Diesel Generator Price List
-
CE Approved China Water Cooled 100kw Silent Diesel Generator Set Powered by Cummins Engine
-
20KW-200KW Open/silent/tralier Cummins 1500 Rpm Generator Price List Powered by Cummins Engine
-
CE ISO China Water Cooled 100kva Generator Set for Emergency Use by Cummins Engine
-
Water Cooled Big Power Plant 1000kw Diesel Generator for Sale
Product Details
| Place of Origin | Liaoning, China | Brand Name | PUYANG | |
| Model Number | PF16GFL | Output Type | AC Three Phase | |
| Speed | 1800rpm | Frequency | 60Hz | |
| Rated Power | 16kw/20kva | Rated Voltage | 440/460VA | |
| Rated Current | N/A |
Product Description
Specifications
generator set for reefer container1.16KW,60Hz,460V OR 440V
2.Yanmar or Laidong engine
3.For reefer container
4.CE certifica
Made in China freshment assurance generator set for reefer container underslung
Tech specification
Genset Model | PF16GFXL | PF16GFXL | ||
GENSET | Rated power(Kw/kva) | 16/20 | 16/20 | |
Frequency(Hz) | 60 | 60 | ||
Phase | 3 | 3 | ||
Voltage(V) | 460 or 440 | 460 or 440 | ||
Fuel capacity(L) | 200 | 200 | ||
Fuel consumption(L/Hour) | 4.8 | 5.8 | ||
Dimension (mm) | L | 1435 | 1520 | |
W | 1160 | 1200 | ||
H | 820 | 960 | ||
Weight(kg) | 570 | 590 | ||
Noise level for silent type (Db/7m) | 70 | 70 | ||
ENGINE | Model | 4TNV88-GGE YANMAR BRAND | 4L22BD-4 LAIDONG BRAND | |
Cylinders | 4 | 4 | ||
Type | Vertical, 4-cycle water-cooled diesel engine | Vertical,4-cycle water-cooled diesel engine | ||
Starting method | Starting motor 12V,1.4kw | Starting motor 12V,1.4kw | ||
ALTERNATOR | Model | GM-16-4 | GM-16-4 | |
Manufacturer | Marathon | Marathon | ||
Insulation class | H | H | ||
Excitation method | Brushless self-excitation | Brushless self-excitation | ||
Warranty:
We provide guarantee for 500 running hours or 6 months for range from the min to 50kW (including 50kW) genset; 1000 running hours or 12 months for range from 50kW to the max genset (whichever comes first). Warranty doesn’t' cover spares such as filters, V-belt, etc. Malfunctions caused by misoperation and careless maintenance will not be considered by us
