Low Blow Moulding Machine Price
- shanghai
- T/T
You May Like
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | PP | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | Yes | Place of Origin | Sichuan, China | |
| Brand Name | YZJ | Model Number | YZJ-160 | |
| Voltage | 380v | Power(W) | 50kw | |
| Dimension(L*W*H) | 6.8*2.3*1.8 | Weight | 6t | |
| Certification | ISO AND BV | Warranty | one year | |
| After-sales Service Provided | Overseas service center available |
Product Description
The machine is human and machine interface that is easily operated. There are single mould base, double moulds base, single mould head to six mould heads, single layer to six layers, multi-layer with liquid level line, mold inside logo, air-pressing water setting, automatic scraps collecting system, the daily output (24 hours) reaches approximately 12,000 to 60,000; it can produce 0.5-2.5L plastic hollow products.
This kind of machine can also produce the material of PE,PP,PA,PC,PVC,PETG,ABS,EVA,K and so on .
1) For container up to 160 liters capacity
2) Accumulating die head single station high performance continuous extrusion blow molding machine
3) Hydraulic proportion control with parts from YUKEN
4) PLC electricity digital control from Siemems with MPT data setting unit
5) Inverter with harden surface gear box
6) Effective energy saving screw design .
7) Central feeding die head overcomes welding line problem .
8) Large arm and joint operation type clamping unit with large and uniform clamping force
Screw Diameter | Mm | 55 |
Screw L/D ratio | L/D | 25:1 |
Capacity PP/PE | Kg/hr | 65 |
Capacity PETG/PC/PVC/PS | Kg/hr | 40 |
Screw speed of rotation | r.p.m | 10-85 |
Extruder heating power | Kw | 7.2 |
Screw heating zone | Zone | 3 |
Extruder driving power | Kw | 15 |
Max container capacity | L | 2.5 |
Number of heating zone | Zone | 3 |
Power of die heating | Kw | 2 |
Max die-pin diameter | Mm | 100 |
Center distance of die | Mm | 120/130 |
Clamping force | Kn | 55 |
Pltaen opening stroke | Mm | 150-350/380 |
Platen size | Mm | 300*320 |
Max mould size | Mm | 390*320 |
Mould thickness | Mm | 150-180 |
Moving-mould distance | Mm | 400 |
Oil pump drive power | Kw | 11 |
Total power | Kw | 35.2 |
Dry cycle | S | 4.5 |
Air pressure | Mpa | 0.6-0.8 |
Air consumption | M³/min | 0.8-1 |
Average energy consumption | Kw | 19 |
Cooling water usage | M³/hr | 2-3 |
Fuel tank capacity | L | 200 |
Machine dimension (W*L*H ) | M | 2.5*3.5*2.5 |
Machine weight | ton | 6 |
|
|
|
