Frp Pultruded Grating With Post Grit
- SHANGHAI
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Jiangsu, China | Model Number | FRPPG | |
| Technics | Other, FRP |
Product Description
Specifications
We supply FRP products contains molded grating, pultruded grating, pultrusion, handrail, ladder and safety cage.
PULTRUDED GRATING
Product process
In this method, continuous fibreglass rovings and mats are pulled through a liquid resign bath, shaped through a series of forming guides, and then drawn through a heated steel die that takes the shape of the resulting part.
Upon existing the die, the part is 90% to 95% cured.
Product features
·Maximum Strength
·Unidirectional
·Light weight
·Low maintenance
Products available
·Color
Standard colors: yellow, gray
Custom colors: any color to match your needs
·Surface
Grit top
Grating with cover(grit,pattern,smooth)
Products specification
In metric
Grating type | height | width | Open area | Bearing bar space | #bearing bar/ft | Bearing bar center | Weight(kg/sqm) |
I series | |||||||
I-6010 | 25mm | 15mm | 60% | 22.5mm | 8 | 38mm | 11.22 |
I-5010 | 25mm | 15mm | 50% | 15mm | 10 | 30mm | 14.63 |
I-4010 | 25mm | 15mm | 40% | 10mm | 12 | 25mm | 17.56 |
I-6015 | 38mm | 15mm | 60% | 22.5mm | 8 | 38mm | 16.10 |
I-5015 | 38mm | 15mm | 50% | 15mm | 10 | 30mm | 19.02 |
I-4015 | 38mm | 15mm | 40% | 10mm | 12 | 25mm | 21.95 |
T series | |||||||
T-1810 | 25mm | 38mm | 18% | 7.5mm | 8 | 45mm | 14.14 |
T-3310 | 25mm | 38mm | 33% | 12.5mm | 5 | 50mm | 12.19 |
T-3320 | 50mm | 25mm | 33% | 12.5mm | 8 | 38mm | 19.51 |
T-5020 | 50mm | 25mm | 50% | 25mm | 6 | 50mm | 15.12 |
In inch
Grating type | height | width | Open area | Bearing bar space | #bearing bar/ft | Bearing bar center | Weight(lb/sqft) |
I series | |||||||
I-6010 | 1" | 0.6" | 60% | 0.9" | 8 | 1.5" | 2.3 |
I-5010 | 1" | 0.6" | 50% | 0.6" | 10 | 1.2" | 3.0 |
I-4010 | 1" | 0.6" | 40% | 0.4" | 12 | 1" | 3.6 |
I-6015 | 1.5" | 0.6" | 60% | 0.9" | 8 | 1.5" | 3.3 |
I-5015 | 1.5" | 0.6" | 50% | 0.6" | 10 | 1.2" | 3.9 |
I-4015 | 1.5" | 0.6" | 40% | 0.4" | 12 | 1" | 4.5 |
T series | |||||||
T-1810 | 1" | 1.5" | 18% | 0.3" | 8 | 1.8" | 2.9 |
T-3310 | 1" | 1.5" | 33% | 0.5" | 5 | 2" | 2.5 |
T-3320 | 2" | 1" | 33% | 0.5" | 8 | 1.5" | 4.0 |
T-5020 | 2" | 1" | 50% | 1" | 6 | 2" | 3.1 |
