Home > Products > Sterilization Equipment > Asepsis Beverage Pipe Sterilizing Machine Ultra High Pasteurizer
Asepsis Beverage Pipe Sterilizing Machine Ultra High Pasteurizer
- ningbo or shanghai port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | HH | Model Number | PLJ | |
| Usage | Other, Fruit & Vegetable | Type | Ultra High Temperature | |
| Voltage | made to order | Power(W) | 15kw | |
| Weight | 270Kg | Dimension(L*W*H) | 150*1500*2500 | |
| Certification | CE | Warranty | 12months | |
| After-sales Service Provided | Overseas service center available |
Product Description
1. For sterilizing of fresh milk, juice, beverage, liquor, soybean milk, etc
2. Stainless Steel.
3. High Efficiency
This machine adopts the present most advanced welding technology, selects the import high quality polish stainless steel pipeline. It is suitable for fresh milk, beverage and wine etc. If completing with the high-pressure even machine, it also can be used for thick material. Our factory is a manufacturer who produced the first over high temperature sterilizing machine in China. At present, there are several thousand set which have been used in the whole country.
According to the various technology request from customers for heating, sterilization, heat-preservation, coolness of various material, we can design several process combination to meet technology standard and make the equipment has all kinds of safeguard measures, the character of high-temperature alarm and reflux. Meantime, we can am high-accuracy automation control system according to the requirement of customers. Use Range: Dairy products, Fruit, Drink, Syrup, Sauce, Vinegar.
Parameter:
Model | RP6L-10 | RP6L-20 | RP6L-40 | RP6L-60 |
Operational Capacity (t/h) | 0.5~ 1.0 | 1.5~ 2.0 | 3.0~ 4.0 | 5.0~ 6.0 |
Sterilizing Temperature (°C) | 115 ~ 135 | 115 ~ 135 | 115 ~ 135 | 115 ~ 135 |
Steam Pressure Used(Mpa) | <0.78 | <0.78 | <0.78 | <0.78 |
High Temperature Heated Time | 4 ~ 6S | 4 ~ 6S | 4 ~ 6S | 4 ~ 6S |
Inlet Material Temperature (°C) (added cooling pipe) | <45 | <45 | <45 | <45 |
Outlet Material Temperature (°C) | <65 | <65 | <65 | <65 |
Steam Consumption (Kg/L) | <0.12 | <0.15 | <0.15 | <0.20 |
Motor Power (kW) | 1.5 | 2.2 | 3 | 4 |
Outside Size (mm) | 920*920*1400 | 1100*1100*1700 | 1200*1200*1800 | 1400*1400*2000 |
Floor Area (m2) | 0.8 | 1.0 | 1.5 | 2.0 |
Net Weight | 280 | 380 | 550 | 700
|
Contact Us
- Hangzhou Huihe Machine Facture Co., Ltd.
- Contact nameAwen Wu Chat Now
- Phone86-571-89774695
- AddressNo.355 Yingbin Road, Yuhang District, Hangzhou City, 311100, China, Hangzhou, Zhejiang
