Oblique Cone Type Extracting Tank for Medicine
US$ 8,450 - 21,500
/ Set
1 Set(Min. Order)
- ningbo or shanghai port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Inclined Cone-type Extracting Tank
-
Stainless Steel TQ-D Multifunctional Extracting Tank
-
TQ-M Multifunctional Extracting Tank(stainless Steel)
-
ZN Vacuum Pressure Reduced Concentration Can
-
Oblique Cone Type Extracting Tank Pharmaceutical Factory
-
Oblique Cone Type Extracting Tank(STAINLESS STEEL) for Pharmaceutical Factory
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | HH | Model Number | Oblique cone type Extracting Tank for Medicine | |
| Voltage | made to order | Power(W) | made to order | |
| Weight | made to order | Dimension(L*W*H) | made to order | |
| Processing Types | made to order | Certification | CE | |
| Warranty | 12 months | After-sales Service Provided | Overseas third-party support available |
Product Description
Inclined Cone-type Extracting Tank(STAINLESS STEEL)
1. sus304
2. 380V
3. extracting usage
4. wooden package
Inclined Cone-type extracting tank can be used in Chinese medicine, food and chemical industries to normal pressure, micro-pressure, water frying, warm soaking, heat cycling, cycling leaking, redolent oil extract and organically solvent recycle. The facilities have the advantages such as high efficiency and simple operating; the CIP cleaning system is in accordance with GMP standards.
Model | TQ-D-0.5 | TQ-D-1.0 | TQ-D-2.0 | TQ-D-3.0 | TQ-D-6.0 | TQ-D-8.0 |
Volume (L) | 750 | 1200 | 2300 | 3400 | 6400 | 8500 |
Designed pressure of tank (Mpa) | 0.09 | |||||
Designed pressure of jacket (Mpa) | 0.09~0.3 | |||||
Compressed air (Mpa) | 0.6~0.7 | |||||
Diameter of charging port (mm) | 350 | 400 | 400 | 400 | 450 | 500 |
Diameter of slag port(mm) | 800 | 1000 | 1200 | 1500 | 1700 | 1900 |
Heating area | 2.0 | 3.2 | 5.3 | 6.8 | 8.5 | 10.5 |
Condensation area | 3 | 5 | 6 | 8 | 10 | 12 |
Cooling area | 0.5 | 1 | 1 | 1 | 2 | 2 |
Energy consumption(Kg/h) | 145 | 195 | 258 | 300 | 552 | 728 |
