25T 2 Axles Low Bed Semi Trailer

Specifications

25T 2 Axles Low Bed Semi Trailer

STRUCTURAL WEIGHT RATTING (estimated):

Tare Weight :       9,500kg               (approximation)

Payload :              25,000kg

G.V.W.R.:              34,500kg               (approximation)

King Pin Weight :  10,500kg               (approximation)

Axle Weight:           24,000 kg               (approximation)

RUNNING GEAR & FRAME:

Suspension:      Undermount double axle suspension with equalizers,7-leaf spring, 26,000kg capacity.

Axle:            FUWA 150×150 square Axle. 13T capacity/set.

Wheel:          6.5-20, 8 pcs made in china.

Tire:             8.25R20, 8 pcs made in china.

King Pin:        2″, bolted type.

Loading ramps:  2 Pcs. 720mm width. Ramps are spring loaded and manually operated with safety chain.

AIR SYSTEM:

Brake:          Dual line pneumatic brake system. WABCO brake valve. With ABS.

Brake chamber:   Type 30/30 spring brake chamber on the 1st axle, type 30 brake chamber on the 2nd axle made in china.

ELECTRICAL:

Voltage:            24 Volt.

Receptacle:          7 way

Light :

Front marker lamp:    White

  Side marker lamp:     Amber

Rear lamp:            Red

Turn signal lamp:      Amber

LANDING LEG:

Leg:              Two speed manual operation type with sand shoe; right handle.

                    Model: TSU.

Rated Capacity:    Static: 80 tons. Lifting: 25 tons.

PAINTING & MARKING:

Color:        Comply with the customer’s request.

Marking:     Comply with the customer’s request.

ELSE:

Side guard: One set (L/R)

Spare tire carrier: One (On gooseneck)

The maximum of pay load is 25,000kg.

All the details are not mentioned above should comply with Chinese standards.
