Borehoe Drilling Rig
- any port in China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Description
Borehoe Drilling Rig
Mobile Drilling Equipment XZ1000 Cummins (392kW) turbocharger water cooling engine, self-propelled steel tracks chassis, high strength assembled drill frame which can adjust to various length drill rods, slidable drill frame (controlled by cylinder), closed circuit and load sensing control hydraulic system, independent cooling system, rack and pinion push-pull, two shift gears speed transfer, all-weather double cab, wire controlling walk, and floating spindle and equipped with truck mounted crane.
Model | XZ1000 | |
|---|---|---|
Engine | CUMMINS | |
Rated power | kW | 392 |
Max.pullback/thrusting | kN | 1000/1000 |
Spindle torque (max) | N.m | 55000 |
Spindle speed | r/min | 0-80 |
Backreaming diameter | mm | Ø1200 |
Tubing length(single) | m | 9.6 |
Tubing diameter | mm | Ø127 |
Entry angle | ° | 10-18 |
Mud flow rate (max) | L/min | 1200 |
Mud pressure (max) | bar | 200 |
Overall weight | kg | 32000 |
Dimension(LxWxH) | mm | 14500×3150×3390 |
