Home > Products > Logistics machinery > SANY container reach stacker machine/ reach stacker 45T
SANY container reach stacker machine/ reach stacker 45T
USD $350,000 - $370,000
/ Unit
1 Unit(Min.Order)
- 100 Unit / Units per Month
- Shanghai
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Hunan, China | |
| Brand Name | SANY | Model Number | SRSC45C2 | |
| Type | Manual Pallet Truck | Power Souce | Diesel Engine | |
| Rated Loading Capacity | 45ton | Max. Lifting Height | 15100mm | |
| Fork Width | 4188mm | Overall Dimensions | 11258*6042*4770mm | |
| Certification | BV,ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Popular SANY 45 ton reach stacker for containers1. Engine VOLVO TWD1240VE
2. Rated power 256 kW/2100 r/min
Sany 45ton Reach Stacker
SANY reach stacker,sany 45 ton reach stacker,SANY 45 ton container reach stacker for sale,SANY reach stacker
Specifications of Sany reach stacker
Reach Stacker
| Overall dimension | |
| Length | 11230 mm |
| Width | 4130 mm |
| Height | 4780 mm |
| Loading capacity | |
| The 1st row | Load center: 1965mm |
| The 1st row | Floor 1-4: 45000 kg |
| The 1st row | Floor 5: 43000 kg |
| The 2nd row | Load center: 3815mm |
| The 2nd row | Floor 1-4: 31000 kg |
| The 3rd row | Load center: 6315mm |
| The 3rd row | Floor 1-3: 15000 kg |
| Engine | |
| Model | VOLVO TWD1240VE |
| Type | In-line 6 cylinders, 4 strokes, central water cooled, turbo charged, electro-injection |
| Control mode | EDC III full electric control system of CAN trunk |
| Rated power | 256 kW/2100 r/min |
| Rated torque | 1751 Nm/1200 r/min |
| Tail gas discharge standard | Euro II |
| Average oil consumption ratio | 197 g/kW.h |
| Gear shifting box | |
| Model | CLARK 15.5HR36432 |
| Gearing mode | Automatic/manual |
| Gears | 4 gears for front and rear respectively |
| Driving axle | |
| Mode | KESSLER+CO D102 PL341 |
| Traveling brake | Multi-sheet wet brake |
| Parking brake | Disk type brake of spring brake and hydraulic release |
| Max. static axle load | 1500 kN |
| Lifting tool | |
| Model | ELME817 |
| Rotary angle | +105 /-195 |
| Side movement distance | +800/-800 mm |
| Max. load-bearing | 45000 kg |
| Available scope | ISC 20-40 |
| Lifting object | Container |
| Overall mass | 69500 kg |
| Arm | |
| Max. hoisting height | 15100 mm |
| Obliquity | 0-60 |
| Travel | 7070 mm |
| Max. hoisting speed (non-load/full load) | 420/250 mm/s |
| Max. traveling speed (non-load/full load) | 25/21 km/h |
| Max. approaching speed (non-load/full load) | 360/360 mm/s |
| Gradeability (non-load/full load) | 39/32 % |
| Max. tractive force | 360 kN |
| Min. turning radius | 8000 mm |
| Steering mode | Servo-aid turning |
| Wheel base | 6000 mm |
| Min. clearance | 350 mm |
| Traveling speed | |
| 1st gear | 3.6 km/h |
| 2nd gear | 8.6 km/h |
| 3rd gear | 14.8 km/h |
| 4th gear | 25 km/h |
| Noisy level at cab | ≤72 dB |
| Temperature of cab | 15-25 0C |
| Lubrication mode | Concentrated lubrication |
| Working pressure of hydraulic system | 23 MPa |
| Total discharge capacity of hydraulic system | 240 ml/r |
