Home > Products > Aerial work platform > 15m articulating boom Self-propelled aerial work platform
15m articulating boom Self-propelled aerial work platform
- any port of China
- T/T
You May Like
-
32m Telescopic boom Self-propelled aerial work platform
-
36m Telescopic boom Self-propelled aerial work platform
-
38m Telescopic boom Self-propelled aerial work platform
-
40m Telescopic boom Self-propelled aerial work platform
-
42m Telescopic boom Self-propelled aerial work platform
-
18m articulating boom Self-propelled aerial work platform
Product Details
| Place of Origin | Hunan, China | Brand Name | SINOBOOM | |
| Model Number | GTZZ15 |
Product Description
Specifications
15m articulating boom Self-propelled aerial work platform1.Platform height 14.8m
2.Lift capacity 250kg
3.Weight 6500kg
15m articulating boom Self-propelled aerial work platform
Item | Measurement | Item | Measurement |
Dimensions | Productivity | ||
Overall length(stowed) | 5.56M (18ft) | Platform height max. | 14.8M (49ft) |
Overall width(stowed) | 2.1M (6ft) | Working height max. | 16.8M (55ft) |
Overall height(stowed) | 2.18M (7ft) | Horizontal reach max. | 7.62M (25ft) |
Ground clearance | 0.23M (0.8ft) | Turntable rotation | 355° |
Wheelbase | 2.2M (7.2ft) | Platform rotation | 160° |
Overall weight | 6500kg (2WD) | Platform Load capacity | 250kg |
7700kg (4WD) | |||
Platform Size (L*W*H) | 1.83*0.76*1.1M (6ft *2.5ft *3.6ft) | Grade ability | 40% (2WD) |
40% (4WD) | |||
Platform levelling | Automatic | Turning radius(outside) | 4.5M (15ft) |
Tire specification | 300-15 | Turning radius(inside) | 1.8 M (6ft) |
Tire type | Solid | Turntable tailswing | 0M (0ft) |
Power | Max. Driving Speed | 7km/h | |
Hydraulic tank vol. | 70L | Driving Speed (stowed) | 0~7km/h |
Hydraulic system vol. (inc. the tank) | 110L | Driving Speed (extended) | 0~1.1km/h |
Fuel tank vol. | 135L | Max allowable wind force | 12.5m/s |
Control voltage | 12V | Max allowable slope | 3° |
Engine | Perkins 404D-22T | Max noise on normal use | 82dB(A) |
Drive & steer model | 2WD*2WS | Max allowable side force | 400N |
