peanut kernel stone removing machine

FOB Price

USD $5,600 - $56,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Shandong, China
Brand Name	XLFY	Model Number	XLFY-9008-2
Application	Candy	Power(W)	3.6-8kw
Dimension(LWH)	as demands	Certification	ISO9001
Warranty	24months	After-sales Service Provided	Engineers available to service machinery overseas

Wolong Peanut Grading Machine/ Peanut Machine

maze,lentil,chestnut,sunflower seeds,grain,peanut processing line

2-6 levels peanut screening machine/peanut grading machine/Peanut classifier

This machine is absorbed the advantages of similar products at home and abroad,

with compact structure, reasonable, high efficiency, save energy consumption,

easy to use the characteristic such as being reliable, applicable in selected peanut kernels,

by a select can achieve precise classification standard. The sprocket, chain drive push rod,

sieve body smooth reciprocating screening, the screen piece made with iron plate punching,

each layer sieve body are returned to the disc, can make the material in the screen piece by the whole process

above screening, and clear materials in the halfway or front screen that is caused by the classification is not clear into

the disadvantages,and each layer sieve bottom after all have certain lists, facilitate the material flow smoothly.

Main parameter of the machine:

NO.	Model	processing capacity MT/H	after insallation dimension(m)	Power(KW)	frequency conversion	screen sheet
1	80-2-7	1	3.51.122.7 6.523.2	1.5		20
2	80-3-7	1.5	3.51.122.6 6.523.2	1.5		30
3	80-4-7	2	3.51.51.7 6.523.5	1.5		50
4	80-5-7	2.5	3.51.121.9 6.523.6	2.2		70
5	80-6-7	3	3.51.122.15 6.524	3		80
6	100-3-7	2	3.61.32.2 7.52.33.2	1.5		30
7	100-4-7	3	3.61.31.7 7.52.33.5	2.2		50
8	100-5-7	3.5	3.61.32.1 7.52.33.9	3		70
9	100-6-7	4	3.61.32.4 7.52.34.2	3		80
10	100-3-10	3	3.61.32.4 7.52.34.2	2.2		40
11	100-4-10	4	4.61.31.9 8.52.33.7	3	4KW	56
12	100-5-10	5	4.61.32.3 8.52.34.2	4		90
13	100-6-10	6	4.61.32.65 8.52.34.5	4		100
14	120-4-7	4	3.61.41.7 7.52.43.5	2.2		50
15	120-5-7	5	3.61.42.1 7.52.43.9	3		70
16	120-6-7	6	3.61.42.4 7.52.44.2	3		80
17	120-3-10
18	120-4-10	5	4.61.41.9 8.52.43.7	3	4KW
19	120-5-10	6	4.61.42.3 8.52.44.2	4
20	120-6-10	7	4.61.42.65 8.52.44.5	4
