Wheel Loader ZL08F with CE Small Farm Loader

Manufacturer :Qingzhou Hongyuan Vehicles Co.,Ltd.

Qingzhou,Shandong,China.

Qingzhou HONGYUAN Mini Wheel Loader ZL08F with CE,Loader for sale,Agricultural Machine ,garden machine.

Main Advantage of ZL08F

1.Fully Hydrostatic Driving

2.CE Approved

3.Noise tests of cabin and body

4.Real Rops&Fops

5.New cabin something like JCB style

6.All loaders are designed under European customers' suggestion.

Standard:

Hydrostatic Transmission System.3 Cylinder Engine.Standard Bucket.Luxury Cabin.E-mark Seat.Adjustable Steering Wheel.Lock For Lifting And Steering Cylinder.Hydraulic Check System.Tipping Cabin.Floating Function.Mechanical Joystick.Easy-damaged Spare Parts

Optional Equipment:

LED Work Light.Quick Hitch.Extra Hydraulic Line.Varta Anti-free Battery

Parameters for ZL08F Wheel Loader

1.0 Engine details:

(1) Model: Changchai 385

(2) Engine type: In-line arrangement, water-cooled, three-cycle diesel Engine

(3) Rated Power: 20KW

(4) Rated Speed: 2200 r/min (rpm)

(5) Fuel Consumption ratio in standard working condition: 269g/kw.h

2.0 Steering System

(1) Cycloid full hydraulic steering system: BZZ-80

(2) System Pressure: 10MPa

3.0 Bucket

(1) Bucket Capacity: 0.4 m3

(2) Bucket width: 1300mm

(3) Bucket type: Heavy-duty bolt on teeth

(4) Max. Breakout Force: 28KN

(5) Rated Load: 800kg

(6) Operating Weight: 2350kg

4.0 Overall Dimensions

(1) Overall Length (Bucket on ground position): 4700mm

(2) Overall Height

(a) Ground to Cab Top: 2350mm

(b) Ground to exhaust pipe: It is below from the top of cabin

(3) Overall Width: 1600mm

 5.0 Operating Specifications

(1) Drive Means: Four-wheel drive

(2) Min Turning Radius: 4600mm

(3) Driving System: mechanical

(4) Dumping Height: 2300mm

(5) Dumping Reach at max height: 750mm

(6) Min the ground distance: 240mm

(7) Time of raise: 4sec.

(8) Hydraulic cycle time: 9sec.

 6.0 Brake System

(1) Service Brake: Four Wheel Hydraulic spread-shoed brake

(2) Parking Brake: Hand operated

7.0 Tyre

(1) Model: 7.50-16 (2) Width: 20cm (3) Diameter: 80cm

8.0 Wheelbase: 2170mm

9.0 Track: 1285mm

Detailed Pictures for ZL08F Wheel Loader :
