Stainless steel wire drawing machine
- 6 Set / Sets per Month
- shanghai or as u need
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | wanyi | |
| Model Number | LZ10/400 | Usage | Drawing |
Product Description
Stainless steel wire drawing machine..
Inlet diameter: φ3.6mm
outlet diameter: φ1.2---φ1.0mm
Inlet wire strenght:≤700MPa
Max. speed :1080m/min
Motor power: 11kw
diameter of roll: 400mm
braking time:normal stop≤30S , emergency stop ≤5S.
drawing machine
Company Published: 2000
Business Type: Manufacturer
Number Of Employees: 100-200 people
Place Of Origin: Zhangjiagang City Jiangsu China
Port: Shanghai
Delivery Time: 55 days
Package: according to your requests(in usually seaworth packing)
Feature: Applicable for continuous drawing and PLC control of frequency transformer drive of high/medium/low carbon steel/alloy steel/stainless steel.
Main technical parameter:
specification | LZ200,LZ 350,LZ 400,LZ450,LZ500,LZ560,LZ600,LZ700 |
Capstan diameter | 200, 350, 400, 450, 500, 560, 600 , 700 |
Drafts | 2-12 |
Max. inlet diameter(mm) | 10 |
Min. outlet diameter(mm) | 0.2 |
speed | According to customers’ requirements |
power | 7.5-90 KW |
capstan | Material is cast steel, coated with tungsten carbide. Surface hardness reaches 60-62HRC. Abrasive resistance is very good. |
Drive system | Adopt 1st or 2nd grade strong narrow V belt; 1st grade strong narrow V belt+ 1st grade hard tooth surface wheel gear with little noise; 1st grade strong narrow V belt+ 1st grade hard tooth surface wheel gear |
Dies case | Water cooling, reasonable installation, can be adjusted up and down, equipped with special device press the button. |
