Home > Products > low carbon steel wire drawing machine > SAE1008/Q195 Wire Drawing Machine
SAE1008/Q195 Wire Drawing Machine
US$ 20,000 - 70,000
/ Set
1 Set(Min. Order)
- Shanghai or as u need
- T/T
You May Like
Product Details
| Condition | New | Type | Wire Drawing Machine | |
| Use | Wire | Place of Origin | Jiangsu, China | |
| Brand Name | WANYI | Model Number | LZ600 | |
| Voltage | 380V | Power(W) | 22X7+15X1KW | |
| Dimension(L*W*H) | 8X1.8X1.5M | Weight | 8000kg | |
| Certification | third part | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description

Specification
| Items | Unit | LZ9-12/1200 | LZ10/800 | LZ9/700 | LZ10/560 | LZ10/400 |
| Reel diameter | mm | 900 | 800 | 700 | 560 | 400 |
| Draw passage | time | 9-12 | 10 | 9 | 10 | 10 |
| Incoming dia | mm | Φ14-8 | Φ10-8 | Φ8-6.5 | Φ6.5-5.5 | Φ14-8 |
| Outgoing dia | mm | Φ5-3 | Φ4-3 | Φ3-2.5 | Φ2-1.8 | Φ1-0.8 |
| Wire darwing line | m/min | 300 | 360 | 480 | 720 | 840 |
| Incoming strength | Mpa | ≤1300 | ≤1300 | ≤1300 | ≤1300 | ≤1300 |
| Total compressibility | % | 87.24-85.94 | 84-85.94 | 85.94-85.21 | 90.53-89.29 | 87.24-84 |
| Average compressibility | % | 20.48-19.58 | 18.42-19.58 | 19.58-19.13 | 21.00-20.02 | 18.61-16.74 |
| Single motor power | Kw | 110-90 | 90-55 | 75-55 | 37-22 | 15-7.5 |
