annealing furnace for low carbon wire drawing machine line

FOB Price

USD $9,500 - $35,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	wanyi
Model Number	pit-type furnace		After-sales Service Provided	Overseas service center available

I ,

Main technical parameters

1,power 180kw

2,Heating elements nickel, chromium flat filament

3,electrothermal distribution upper middle and lower

4,maximum temperature 950°C

5, continuous operating temperature 900 °C

6, furnace surface temperature rise: ≤ 45 °C + at room temperature

7, power 380 / V/ 50Hz, 3-phase

8,connecting mode Y,

9,temperature control accuracy ≤±2°C

10, the effective size of internal furnace φ1600*1700

11, loading capacity 6000kg/Furnace/10h
