Two/three hopper concrete dosing machine

Two/three hopper concrete dosing machine  :

Concrete dosing machine application:

PLD series concrete batching /dosing machine is a mixer supporting the use of the front desk with automatic dispending equipment. They can finish batching program automatically which include sand, stone, concrete and other ingredients of 3-6 materials program according to the design of the user.

The machine adopts electronic weighing ,microcomputer control, digital display, remote control, with accurate weighing, batching of high precision, fast speed, the advantage of strong control function, it’s easy to operate, just press a button every time. This series concrete batching machine can be combined into different forms, different specifications of combined-type mixing plant with the corresponding concrete mixer, and the cost is only half or a third of the same specification mixing station, in addition, mobile installation is very convenient ,it is a ideal equipment in the field production in field production high quality concrete

Concrete dosing machine working process:

Firstly, material 1 belt conveyor start to work, delivery material 1 to weighing hopper, when the weight of inside material of weighing hopper reaches the set value, the material 1 belt conveyor will automatically stop;

Then the material 2 belt conveyor start automatically , when the material weight of hopper reaches the quantity of set value of material 1 and material 2, material 2 belt conveyor will stop, material 3 belt conveyor just start to work, after these four materials are ready, the machine will be in a waiting state. At this moment press discharging button, discharging belt conveyor just start to work, discharge the configured concrete dry into mixer hopper.

When discharging finishes, discharging belt conveyor will stop automatically, and starts the second loop ingredients automatically, when the second loop ingredients finishes, waiting for discharge again, it will be circulating.

Concrete dosing machine main technical parameter:
