Dry Process Ball Mill Plant With Dust Collector

Dry Process Ball Mill Plant With Dust Collector  :

(1) Save energy: bush bearing is replaced by rolling bearing, friction resistance being greatly lowered down,

 easy to be started. It’s energy is lower 10-15% than the old one.

 (2)Large capacity: for the outlet disk and the checked liner are adopted, the capacity is higher 20% than

 the cone ball mill.

(3)The discharging port slurry surface is low, slurry flow through rapidly, decrease ore over-grinding.

( 1) open circuit dry ball mill

Ball mill open circuit grinding is the simplest form of technology. Open system has the advantages of simple process, less investment, easy operation and maintenance. Disadvantage is a serious of the over mill grinding phenomenon, low efficiency, high power consumption, difficult fineness adjustment.

( 2) closed circuit dry ball mill:

Closed circuit grinding is widely used all over the world in cement production process, United States, Germany, France, Japan and other developed countries almost all large grinding system with closed circuit grinding. For example, more than 95% of total Japanese cement output is by closed circuit grinding system.

Closed- circuit system consists of ball mill, separator and transmission equipment, dust collection equipment and other auxiliary components. Closed- circuit system can eliminate the over-grinding phenomenon,and have the characters of high efficiency, low power consumption ,output than the same specifications of open circuit grinding improved 5% to 50%, convenient fineness adjustment. But the defects are complex process, large investment, inconvenient operation and maintenance.

(3) pre-grinding system

Before the material into the ball mill ,it is pre-crushed by other grinding equipment so as to minify particle size, improve the yield and reduce power consumption of grinding system.
