Product Details
| Condition | New | Usage | Other, cotton seed oil | |
| Type | Other, Cold & Hot Pressing Machine | Automatic Grade | Automatic | |
| Production Capacity | 20T/D | Place of Origin | Henan, China | |
| Brand Name | HDC | Model Number | HDC15 | |
| Voltage | 380V/50HZ | Power(W) | 23.5KW | |
| Dimension(L*W*H) | 1700*1300*1600 | Weight | 780kg | |
| Certification | CE, ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
20TPD Automatic cotton seeds oil extraction press cottonseed oil processing plant with CE
Why choose us?
1.We are Alibaba Assessed Gold Supplier for cotton seed oil processing plant .
2.We are a factory manufacturing edible oil machine,best production capability,best quality control, Best Service.
3.Inspected by the Inspection Institution of Bureau Veritas Certification.
4.100% QC inspection Before Shipment.
5. CE listed,competitve price cotton seed oil processing plant .
Please contact Vivian Deng for a quotation
(Tel/whatsapp/skype:+86 155 2728 0372,email:vivian at )
Specifications:
1. Coconut oil processing plant
2. suitable for soybean, corn germ, peanut, sesame, rapeseed, rice bran, cottonseed, tea seed, sunflower seed oil press
3. pure oil, edible oil quality
4. various capacity: 10t/d, 20t/d, 30t/d, 40t/d, 50t/d, 60t/d, 70t/d, 80t/d,100t/d, 150t/d,200T/D
5. Applicable for hot and cold press
Operation Process of Oil Press Machine:
1. Prepare raw materials
2. Adjust the machine, i.e. checking electricity, beginning heating (if it is cold pressing,heating is not needed.)
3. Open the machine, put seeds into the hopper.
4. Seeds flowed from hopper into screw bolt, pressing begins.
5. While pressing of oilseeds, crude oil flowed thought the board then into the vacuum filters; and cakes discharged from outlet;
6. Once finished oil pressing, press stop button, then operation finished.
Leaching Section Processing of Oil Extraction Machine:
1. The material (for pretreatment) is sent to rotary extraction by the scraper conveyor. The material will extracted by the solvent or mix oil. After this step, we will get meal and mix oil.
2. Meal is sent to toaster. Through the toaster, the solvent in the meal will separate from the meal. The solvent goes to condenser and is recycled to rotary extraction.
3. After the mix oil from the rotary extraction enters into 1st evaporator and 2nd evaporator, most of the solvent in the mix oil is separated.
4. The mix oil from 2nd evaporator goes to stripping tower and almost all the solvent is separated. From the stripping tower, we can get crude oil and solvent. The solvent is sent to condenser and is recycled to rotary extraction.
The refining section main parts of Oil Machine:
1. Deacidification tank, used for acid refining, alkali refining and hydration
2. Bleaching pot, used for removing off pigments, bleaching oils and grease dehydrate
3. Deodorization pot, used for removing fatty acid and other rare delicacy high efficiently
4. Conduction oil heater, used for providing the heat energy
5. The vacuum pump, used for providing vacuum for bleaching, deodorization which can reach 755mmHg or more
6. Air compressor, used for drying bleaching earth
7. Pressure filter, used for filtering bleaching earth
8. Steam jet ejector pump, providing steam for Deodorization and distillation
Engineering design scope of oil pressing machine and sunflower oil press machine and peanut oil press machine
1). Craft flow chart;
2). Equipment layout drawing;
3). Equipment base drawing;
4). Reserved hole & embedded parts drawing and civil engineering condition drawing;
5). Embedded pipeline layout drawing;
6). Embedded pipeline of power circuit drawing;
7). Power electricity layout drawing;
8). Electricity distribution cabinet and operation table schema;
9). Plant layout drawing.
After-sales service scope of oil pressing machine and sunflower oil press machine and peanut oil press machine
1). Equipment installation & commission guidance and training work: buyer offers round-trip
air tickets, VISA fee, salary, local food & accommodation and other related charges for the
engineer.
2). Warranty period: one year, offering long-time free technology service
