Wholesale High Quality Pet Bottle Aluminum Foil Sealing Machine

 Wholesale High Quality Pet Bottle Aluminum Foil Sealing Machine

>>>>> Way To Work

1 / Filling, driven by cylinder photoelectric induction to the bottle into the automatic filling.

2 / The company produced fully automatic filling machine series are all touch screen operation, on the basis of the original models on the market increased a lot of practical function.

3 / All parts contacting with materials are the links for quick release type, without special tools.

>>>>> The Basic Comfiguration

1 / The whole stainless steel -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- SU304

2 / Material contact part of the stainless steel -- -- -- -- -- -- ----SU304

3 / The rest parts material -- -- -- -- -- -- -- -- -- -- hard alumina except

4 / Material contact parts (stainless steel) -- -- -- -- -- -- -- -- -- -- --PP

5 / Filling master cylinder -- -- -- -- -- -- -- -- -- -- -- ---Shanghai STNC

6 / Filling head cylinder -- -- -- -- -- -- -- -- -- -- -- -- - Shanghai STNC

7 / PLC control system -- -- -- -- -- -- -- -- -- -- -- --Japan MITSUBISHI

8 / OPTO-electronic components -- -- -- -- -- -- -- -- -- - -- -AUTONICS

9 / Low voltage electrical appliances -- -- -- -- -- -- -- -- -- Japan OMROM

>>>>>  Technical Parameter

1/ Supply voltage: 220 v ac

2 / Pressure: 5-8 kg

3 / Power: 3 KW

4 / Gas: 60 LITRES minute

5 / Filling quantity: 25-150 ml

6 /Filling accuracy: 0.5%

7 / Filling speed: 20-40 bottles/minutes

The basic configuration and technical parameters

The way to work PLC control multiple components, vacuum suction feeding valve to open, will feed valve closed when playing, filling valve opened at the same time, to achieve the effect of filling, the size of the filling amount through touch screen man-machine interface operation, equipped with an automatic screw cap, automatic cover, automatic into the screw cover location, automatic screw cap body will cap lock. Using shock type cap under way, after filling procedure automatically cap under pressure.

The technology and configuration requirements

1 Filling head push down by cylinder filling, filling each cylinder descend to bottle, when dose can be adjusted.

2 The self-priming absorption material.

3 Have no bottle no filling function.

4 The machine automatically on the plug and screw cap function.

Guangzhou Jinfeng Light Industry Machinery Co., Ltd. is a manufacturer that produces cosmetic, pharmaceutical, chemical and dairy equipment. We undertake equipment design, manufacture, installation, maintenance, technical improvement support, technical consultancy and other services. Our main products are vacuum homogeneous emulsifying machines, reverse osmosis water treatment machines, automatic and semi-automatic filling machines and all kinds of stainless steel tanks. All of them are of reliable quality and good effect. We have more than ten years' experience in machinery manufacturing and our products have been entered into domestic and overseas markets. The diverse products with high quality can meet various needs of industries mentioned above.

Jinfeng focuses on creating value for customers. We not only provide installation service, but also help customers design and select equipment according to existing sites. After-sales Department specifically organizes clients to carry out debugging. We also offer one-year warranty and lifetime maintenance. The after-sales hotline is opening the whole day and we are willing to provide consulting service for you. We value the good relationship with customers. We serve customers in domestic and international markets, and have won a good reputation. "With credit to survive and develop" is our philosophy.

Package Detail:

• Wooden case  / carton

 Shipping Details:

• Usually by sea

Delivery Time:

• 20-25 working days after received the deposit
