Trailer Ball Bearing Turntable
US$ 35 - 180
/ Piece
5 Pieces(Min. Order)
- Xiamen Tianjin
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | TINMY | |
| Model Number | TMTS500-D01 |
Product Description
Specifications
Trailer Ball Bearing Turntable1)Type:Z, UA, UB type Turntable
2)Size:400mm~1308mm
3)Used:Trailer & Tractor
4)Tonnage:20ton
Ball Bearing Turntable
1)Type:Z type,UA type,UB type
2)Size:400mm~1308mm
3)Used: semi-trailers, full trailers and tractors.
4)Tonnage:20ton
5)Ball:Single,Double
6)Casting, Forging
7)Certificate:ISO9001:2000 /TS16949
Details:
| Item No. | A | B | E | F | H | Weight | Ring Thickness | Ball Dia. |
| mm | mm | mm | mm | mm | kg | mm | ||
| TMTD650-B01 | 650 | 665 | 552 | 510 | 80 | 74 | 14 | 16/19 |
| TMTD880-B01 | 880 | 895 | 780 | 740 | 80 | 80 | 14 | 16/19 |
| TMTD1096-B01 | 1096 | 1110 | 990 | 950 | 80 | 100 | 14 | 16/22 |
| TMTD1000-B01 | 988 | 1000 | 870 | 830 | 92 | 88 | 14 | 16/19 |
| TMTD1100-B01 | 1095 | 1108 | 975 | 940 | 92 | 100 | 15 | 16/22 |
| TMTD1200-B01 | 1195 | 1208 | 1076 | 1040 | 92 | 118 | 15 | 16/22 |
| TMTD1200-B02 | 1198 | 1215 | 1075 | 1040 | 92 | 120 | 16 | 16/22 |
| Item No. | A | B | E | F | H | Weight | Ring Thickness | Ball Dia. |
| mm | mm | mm | mm | mm | kg | mm | ||
| TMTS500-D01 | 500 | 437 | 379 | 310 | 52 | 25 | 10 | 16 |
| TMTS650-D01 | 650 | 587 | 523 | 465 | 52 | 32 | 10 | 16 |
| TMTS750-D01 | 750 | 687 | 620 | 565 | 52 | 36 | 10 | 16 |
| TMTS850-D01 | 850 | 787 | 723 | 665 | 52 | 41 | 10 | 16 |
| TMTS950-D01 | 950 | 888 | 820 | 752 | 56 | 45 | 12 | 16 |
| TMTS950-D02 | 952 | 885 | 821 | 750 | 60 | 48 | 12 | 20 |
| TMTS1050-D01 | 1050 | 987 | 923 | 865 | 52 | 53 | 12 | 16 |
| TMTS1100-D01 | 1102 | 1027 | 923 | 854 | 56 | 61 | 12 | 20 |
| Item No. | A | B | E | F | H | Weight | Ring Thickness | Ball Dia. |
| mm | mm | mm | mm | mm | kg | mm | ||
| TMTS500-A01 | 500 | 500 | 392 | 376 | 55 | 32 | 10 | 16 |
| TMTS685-A01 | 685 | 700 | 590 | 565 | 80 | 45 | 13 | 16 |
| TMTS880-A01 | 880 | 895 | 779 | 754 | 80 | 60 | 13 | 16 |
| TMTS1000-A01 | 1000 | 1015 | 885 | 860 | 80 | 76 | 14 | 22 |
| TMTS1000-A02 | 1022 | 1013 | 879 | 856 | 90 | 85 | 14 | 22 |
| TMTS1000-A03 | 1000 | 1015 | 885 | 860 | 90 | 84 | 14 | 22 |
| TMTS1100-A01 | 1100 | 1115 | 985 | 960 | 90 | 98 | 15 | 22 |
| TMTS1100-A02 | 1100 | 1111 | 983 | 949 | 90 | 98 | 15 | 22 |
| TMTS1200-A01 | 1200 | 1211 | 1083 | 1050 | 90 | 110 | 15 | 22 |
| TMTS1300-A01 | 1300 | 1315 | 1180 | 1146 | 90 | 118 | 16 | 22 |
| TMTS1300-A02 | 1300 | 1315 | 1185 | 1160 | 90 | 118 | 16 | 22 |
