Home > Products > Landing Gear > 30ton Container landing gear
30ton Container landing gear
- Xiamen Qingdao
- T/T Credit Card PayPal
You May Like
Product Details
| Parts | Trailer Suspension | OEM No. | TMLO-30 | |
| Max Payload | 80 TON | Size | 25Ton - 35 Ton | |
| Place of Origin | Fujian, China | Brand Name | TINMY | |
| Model Number | TMLO-30 |
Product Description
Specifications
Container landing gear1,Gear box Inside & Outside
2,Capacity:9ton,11ton,25ton,28ton,30ton,35ton
3,JOST,FUWA,HOLLAND Type
Container landing gear
Gearbox Inside details
| Item No. | Travel | Static Capacity | Lifting Capacity | Lift Speed/turn | Weight (Kg) | Remarks | |
| max | min | ||||||
| TMLI-25 | 14"/17"/19" | 80T | 25T | 6 | 0.67 | 100 | single-side operation |
| TMLI-28 | 14"/17"/19" | 80T | 28T | 7.5 | 0.83 | 102 | single-side operation |
| TMLI-30 | 14"/17"/19" | 80T | 30T | 7.5 | 0.7 | 108 | single-side operation |
Gearbox Outside details
| Item No. | Travel | Static Capacity | Lifting Capacity | Lift Speed/turn | Weight (Kg) | Remarks | |
| max | min | ||||||
| TMLO-25 | 14"/17"/19" | 80T | 25T | 4.33 | 0.57 | 108 | single-side operation |
| TMLO-28 | 14"/17"/19" | 80T | 28T | 5.42 | 0.72 | 110 | single-side operation |
| TMLO-30 | 14"/17"/19" | 80T | 30T | 5.42 | 0.72 | 116 | single-side operation |
| TMLO-35 | 14"/17"/19" | 80T | 35T | 5.42 | 0.72 | 120 | single-side operation |
Note:
1, Gear box inside and outside with JOST,FUWA , Holland type for semi trailer.
2, The main capacity including 9ton,11ton,25ton,28ton,30ton,35ton.
Also 3tons and 6 tons landing gear are available.
3, Competitive price and high quality.
4, Certificate: ISO/TS16949
Function & Attention:
1, Landing Gear is one of the important equipments of semi-trailer. It is adopted to lift and load semi-trailer after leaving and to use as lifter while vehicle maintenance.
2, Landing Gear has slow and fast two speed. Please use slow speed when loading. It is easy to operate. Do not use fast speed. It is possible to injure landing gear.
