Home > Products > Agricultural Machine > TINMY Hydraulic Cylinder
TINMY Hydraulic Cylinder
- Xiamen etc.
- T/T Credit Card
You May Like
Product Details
| Standard or Nonstandard | Standard | Structure | Piston Cylinder | |
| Power | Hydraulic | Body Material | Steel | |
| Maximum Stroke | 5000mm | Shaft Diameter | 30mm to 500mm | |
| Place of Origin | Fujian, China | Model Number | TINMY hydraulic cylinder | |
| Brand Name | TINMY |
Product Description
TINMY hydraulic cylinder:
1. Usage: machine tool, industrial machinery
2. High quality and competitive price
3. ISO/TS16949 certified
Parameter Information
Item | TINMY hydraulic cylinder | ||
Cylinder inner diameter | 32,40,50,63,80,100,125,160 | ||
Supporting type | SD,LA,LB,FA,FB,CA,CB,TA,TC | ||
Working pressure | 3.5MPa, max. 32Mpa | ||
Max.allowable pressure | 4.5MPa | ||
Wthstand voltage | 5.0MPa | ||
Min. operating pressure | 0.1MPa | ||
Max operating speed | 300mm/s | ||
Min operating speed | 8mm/s | ||
Maximum stroke ( 5000mm) |
cylinder inner diameter | 32 | 800 |
40 | 1000 | ||
50,63 | 1200 | ||
80 | 1600 | ||
100 | 1600 | ||
125,160 | 1800 | ||
Stroke tolerance | |||
The piston rod head thread precision | JIS B 0211-6g(2 level) | ||
Ambient temperature range | -10~ + 80°C | ||
Xiamen Tinmy Autoparts Co., Ltd., which belongs to Tinmy Group, is a leading manufacturer in auto parts that organized by several factories and successfully certified with TS16949 and ISO9001/2000 quality control system.
OEM service provided.
Complete & considerate after-sale service.
By standard seaworthy packing.
If you have any special request, feel free to tell us.
