Home > Products > Switching Power Supply > Switching Power Supply 75W Single phase output S-75-24

Switching Power Supply 75W Single phase output S-75-24

FOB Price

USD $5 - $30 / Piece

10 Pieces(Min.Order)

Port Shanghai
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	YUMO
Model Number	S-75-24	Output Power	51 - 100W
Output Type	Single	Input Voltage	220V
Output Voltage	DC5V,12V,15V,24V	Output Frequency	50HZ
Output Current	2.1-10A

Product Description

Specifications

Switching Power Supply 75W Single phase output S-75-24

Product Description

switching power supply,switch power supply,DC power supply
Protection:Over load,over voltage,short circuit
Professional export

1.Low price and high reliability
2.105 output capacitor
3.AC input power suitable for the world
4.High efficiency and low operation temperature
5.Soft-start current can reduce the AC input impact effectively
6.With short-circuit and overload protection
7.Compact size, light weight
8.100% full-load burning test
9.Installed with EMI filter, minimum wave

85-130/170-264V 50/60Hz
24V 0-3A
CE ROHS
159*97*38mm

model
Performance S - 75-75-5 S - 12-75-15 "S" S - 75-24
Output voltage dc 12V 5V 15V 24V
Output voltage tolerance of ± 2% (2) ± 1% of ± 1% of ± 1%
Rated output current 15 years 6.3 A 5A 3.2
Output current range 0-0-0 deg 4.2 A 3.4 - A 0-2.1
Ripple noise (3) 70mVp - p 100mVp - p 100mVp - p 100mVp - p
In the stability (note 4) ± 0.5% ± 0.5% ± 0.5% ± 0.5%
Load stability (note 5) ± 1% ± 0.5% ± 0.5% ± 0.5%
Dc power output 75W 75.6 W 75W 7.68 W
Efficiency 71% 78% 78% 82%
Dc voltage adjustable scope + 10-5% ± 10% ± 10% ± 10%
Input voltage range from 85 132VAC / 47-63Hz, 170-264VAC by switching selection 63Hz; 47 - 240-370VDC
The input current 1.6 A / 115V 0.8 230V/A
Current cold start current 18A 36A 230V / 115V /
Leakage current < 0.5 mA / 240VAC
Overload protection 105% ~ 150 type: PULSING HICCUP: automatic SHUTDOWN reset
Over-voltage protection 105% ~ 150%
High temperature protection...
The temperature coefficient (0 ~ 0.03% ± 50 ° c),
Start up, maintain and 200ms time, 30ms 100ms,
10 ~ 500Hz extent, 2gb 10min. / 1 cycle, duration 60 points, the axis
Sex between input and output voltage 3KVAC: input, output KVAC shell: 1.5 KVAC: 0.5 shell
The input and output, isolating resistor between input and output and the shell, 500VAC / 100M shell: Ohms
Working temperature, humidity - 10 ° ~ + 60 degrees, the 20% ~ 90% RH
Storage temperature, temperature - 20 ° ~ + 10% ~ 85 ° c, 95% RH
Shape dimension 38mm * * 97 159 shell: 901
Weight 0.5 Kgs
Safety standards, TUV EN60950 UL1012 meet
EMC standards comply with IEC801-4, IEC555-2
Note: 1, the above parameters test conditions for rated load 230VAC: input, 25 °, humidity 70% RH.
2, tolerance, including setting tolerance, stability, load stability (note 5).
3 and the ripple 20MHz test: with A12 "twisted-pair cable, interrupted by 0.1 uF & 47uF capacitor circuit.
4, into line voltage stability test: full load into the lowest to the highest line voltage voltage.
5 and stability test: load load from 0% to 100%.
6 and C2 3,6, must be pulled down

S-15-3,S-15-5,S-15-12,S-15-15,S-15-24,S-15-36,S-15-48,S-25-3,S-25-5,S-35-7.5,S-25-12,S-15-15,S-25-24,S-25-36,S-25-48,S-35-5,S-35-12,S-35-13.5,S-35-15,S-35-24,S-35-36,S-40-5,S-40-12,S-40-24,S-40-15,S-50-5,S-50-12,S-50-13.5,S-50-15,S-50-24,S-50-36,S-50-48,S-60-5,S-60-12,S-60-15,S-60-24,S-75-5,S-75-12,S-75-15,S-75-24,S-75-36,S-75-48,S-100-5,S-100-7.5,S-100-12,S-100-13.5,S-100-15,S-100-24,S-100-36,S-100-48,S-145-5,S-145-12,S-145-13.5,S-145-15,S-145-36,S-145-48,S-145-24,S-150-5,S-150-12,S-150-13.5,S-150-15,S-150-36,S-150-48,S-150-24,S-201-5,S-201-12,S-201-13.5,S-201-15,S-201-36,S-201-48,S-201-24,S-240-5,S-240-12,S-240-13.5,S-240-15,S-240-36,S-240-48,S-240-24,S-250-5,S-250-12,S-250-13.5,S-250-15,S-250-36,S-250-48,S-250-24,S-350-5,S-350-12,S-350-13.5,S-350-15,S-350-36,S-350-48,S-350-24,S-400-5,S-400-12,S-400-13.5,S-400-15,S-400-36,S-400-48,S-400-24,SP-500-12,SP-500-24,SP-500-13.5,SP-500.
