DH48J YUMO Counting Relay/ Digital Counter

  DH48J YUMO  counting relay/ Digital counter

Main feature:

 1. Operating voltage: AC12~380V, 50Hz, DC12-48V
2. Delay time range: Count range 1~9999(x1/x10/x100)
3. Counting speed:30times/s

4. Working model: According to input signal of contact count
5. Mounting style: Moungting panel style
6. Outline dimensions: 48 x 48 x 122mm
7. Mounting dimensions: 46 x 46mm

8.Contact capacity:AC220V 3A,DC28V 3A

9.Huminity:35%~85%

10.Life:Mech:10000000;Elec:10000

11.Weight:100g

12.Counting method:Accumulator

Important Information about counter Conditions

1. All of the counters are brand new, top quality components: absolutely no used items or counterfeits.

2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.

3. Prices, specifications, and availability of all items are subject to change without notice.

4. We are not responsible for typographical errors.

Payment Terms

- We accept payments made by Western Union,TT,PayPal.

-Since you made the payment successfully, you can send us the Reference NO or MTCN.

Shipping

1.We will ship the items within 5 working days after the payment is reached.

2.We ship to you by Express.

3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.

4.Any import fees or charges are the buyer's responsibility.

Warranty

Warranty is available based on the following points:

1.The counter are guaranteed for one year.

2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t   o manufacturers specifications, simply return them to us for replacement or refund.

3.If the items is defective, please notify us within 3 days of delivery.

4.Any items must be returned in their original condition to qualify for a refund or replacement.

5.The buyer is responsible for all the return shipping cost incurred.
