Water-cooled Slient Diesel Generator 15kw

Technical data

Genset Model

16GF

Genset Output Power

20KVA

Rated Voltage

380/220V

Frequency

50Hz

Power Factor(COS)

0.8(lagging)

Dimension (L×W×H) (mm)

2000×900×1200

Net weight (kg)

1100

Diesel Engine

Brand

DCEC Cummins

Model

4B3.9-G2

Engine Structure

In line 4 cylinder, 4 stroke, turbocharged

Rotating Speed

1500r/min

Engine Cooling Method

Radiator for ambient temp 40^OC, belt driven cooling fan with cover

Governor System

Precise electrical governor system

Starting Method

12V DC, with Silicon commutating charging motor

Engine Filter System

Dry type air filter, fuel filter, oil filter

Displacement(L)

3.9

Compression Ratio

16.51

Bore×Stroke(mm)

102×120

100% load fuel consumption (L/h)

6.7

Lube capacity(L)

10.9

Alternator

Brand

Chinese Stamford

Excite Type

Brushless ,Self-exciting, AVR automatic voltage regulating

Connecting Type

3 Phase and 4 Wires

Steady Frequency Change

05%

No load voltage

≥95%105%

Steady voltage

≤±1%

Insulation degree

H degree

Enclosure degree

IP21

The components of the genset

(1) Diesel engine; (2) Generator; (3) Control panel; (4) Silent box

The Accessories

Wave pipe , curved pipe , muffler , accumulator and the connecting lines , shock-absorbing spacer , and data .

Control Panel

The control panel is Ordinary integrative type control panel, with the display of voltage,current, frequency, water temperature, oil pressure.
