Weichai Ricardo 125 KVA 100KW Diesel Generator Set
US$ 1,000 - 10,000
/ Set
1 Set(Min. Order)
- Qingdao
- T/T
You May Like
-
Weichai Styre 250KVA/200KW Diesel Generator Set
-
20KW-500KW Diesel Generator Set With CE/ISO Quality Certificate
-
Chinese Best Quality Generator, Diesel Engine With Stamford Original Alternator
-
Weichai Diesel Generator 62.5KVA/50KW
-
Weichai K4100d Diesel Generator Set 30kw Diesel Generator With Ricardo Engine
-
Best Quality CE Approved 500kw Water Cooled Generator Price List/ Diesel Generator Set
Product Details
| Place of Origin | Shandong, China | Brand Name | Huatian | |
| Model Number | 125kva | Output Type | AC Three Phase | |
| Speed | 1500/1800 r/min | Frequency | 50/60 Hz | |
| Rated Power | 100kw | Rated Voltage | 400V | |
| Rated Current | 180A |
Product Description
Weichai Ricardo 125 KVA 100KW Diesel Generator Set
Product Description
| Specification of genset | ||||||||
| Gensets model | 120GF | |||||||
| Prime power(KW) | 120 | |||||||
| Rated voltage(V) | 400 / 230 | |||||||
| Rated current(A) | 217 | |||||||
| Rated frequency(HZ) | 50 | |||||||
| Rated Speed (rpm) | 1500 | |||||||
| Power Factor | 0.8(lagging) | |||||||
| Dimensions(mm) (L×W×H) | 2450x930x1730 | |||||||
| Genset Weight(kg) | 1700 | |||||||
| Specification of diesel engine | ||||||||
| Engine brand | Weifang Huatian | |||||||
| Engine model | R6105IZLD | |||||||
| Air Intake System | Turbocharged | |||||||
| Fuel System | Direct Injection | |||||||
| Cycle | Four stroke | |||||||
| Cylinder Arrangement | 6 in line | |||||||
| Displacement | 7.01L | |||||||
| Bore×Stroke (mm×mm) | 105 x 135 | |||||||
| Rated RPM | 1500rpm | |||||||
| Cooling System | Forced Water Cooling Cycle | |||||||
| Governor Type | Mechanical | |||||||
| Fuel Consumption at 100% Load (g/kwh) | 238 | |||||||
| Starting Method | DC24V electrical starting | |||||||
| Specification of alternator | ||||||||
| Alternator brand | Chinese Stamford | |||||||
| Excitation | Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire | |||||||
| Number of Phase | 3 | |||||||
| Connecting Type | 3 Phase and 4 Wires | |||||||
| Number of Bearing | 1 | |||||||
| Power Factor | 0.8 | |||||||
| Protection Grade | IP21 | |||||||
| Altitude | ≤1000m | |||||||
| Insulation Class, Temperature Rise | H | |||||||
| Telephone Influence Factor (TIF) | ≤50 | |||||||
| THF | ≤2% | |||||||
| Voltage Regulation, Steady State | ≤±1% | |||||||
| Transient State Voltage | ≤-15%~+20% | |||||||
| Specification of control Panel | ||||||||
| The control panel is common integrated control panel, with the display of voltage,current, frequency, water temperature, oil pressure. | ||||||||
Packaging & Shipping
Export Standard Plywood case
Our Services
Manager: Alex Zhang
Mobile: 0086-15169542396
Whatsapp: 0086-15169542396
Viber: 0086-15169542396
Skype: alex_enginegenset
Company Information
1. Weifang Huatian Diesel Engine Co., Ltd is specialized in diesel engines,gas engines, diesel generators, gas generators, diesel water pump sets and Weichai spare parts.
2. HUATIAN Brand Diesel Engines cover power from 20hp-400hp,,with 2 cylinders,4 cylinders and 6 cylinders.
3. Generator sets are chosed Cummins, Perkins, Deutz, Steyr,Ricardo diesel engines, matching with Stamford, Marathon, Leroy Somer brand alternators, from 10kva to 1000kva.
4. Weichai diesel engines and generators spare parts are all genius. All accessories have been in stock for 1 to 2 days goods deliveried.
Contact Us
- Weifang Huatian Diesel Engine Co., Ltd.
- Contact nameJohn zhang Chat Now
- Phone0086-536-8816750
- AddressNo.15,Airport South Road ,Kuiwen District, Weifang, Shandong
