Small Type Diesel Gensets 15kw ChangChai Diesel Generator With S1115 Engine

FOB Price

US$ 1,000 - 10,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Small Type Diesel Gensets 15kw ChangChai Diesel Generator With S1115 Engine

Product Description

Technical Specifications
Diesel Generator Set	Model No.	HT15GF
	Rated output(KW/KVA)	12/15
	Standby output(KW/KVA)	15/18.75
	Size(mm)	1300700900
	Weight(KG)	460
Diesel Engine	Model No.	S1115
	Engine characters	Straight line, watecooling, four stroke,direct injection
	Rated output(KW/KVA)	16.2/20.25
	Standby output(KW/KVA)	17.82/22.28
	Cylinder NO.	1
	Aspiration	Natural aspiration
	Bore(mm)*Stroke(mm)	115/115
	Compression ratio	17:1
	Displacement(L)	1.194
	Start type	DC 12V electric start
	Rated Speed(rpm)	1500
	Rated fuel consumption(L/h)	≤244.8(g/kw.h)
Alternator	Model No.	STC-15
	Continuous output(KW/KVA)	15/18.7
	Voltage Control	AVR
	Excitation type	Brush/Brushless
	Insulation class	H
	Brand	Stanford/Stanford copy
	Voltage(V)	230/400
	Current(A)	27
	Frequency(HZ)	50HZ
	Power Factor	0.8
	Phase	3 phases, 4 wires
