Home > Products > FILAMENT & FLAT YARN > PP PE FLAT YARN MAKING MACHINE AND STRETCH LINE,RECYCLED PP PE FLAT MONOFILAMENT EXTRUSION LINE.flat Yarn Making Machine
PP PE FLAT YARN MAKING MACHINE AND STRETCH LINE,RECYCLED PP PE FLAT MONOFILAMENT EXTRUSION LINE.flat Yarn Making Machine
US$ 100,000 - 500,000
/ Set
1 Set(Min. Order)
- China Port
- T/T
You May Like
-
PLASTIC MONOFILAMENT YARN EXTRUDER MACHINE,monofilament Yarn Machine
-
CE STANDARD PP PET MONOFILAMENT YARN MAKING MACHINERY
-
Plastic Filament Extruding Machine,pet Monofilament Yarn Extruding Line
-
PLASTIC MONOFILAMENT YARN EXTURDER MACHINE,polypropylene Yarn Machine
-
PP Monofilament Yarn Extruder Machine For Brush
-
PET Polyester Monofilament Yarn Making Machine
Product Details
| Application | Wire | |||
| Plastic Processed | Other, PP/PE/PET pellet or flakes | Screw Design | Single-screw | |
| Automatic Grade | automatic | Place of Origin | Jiangsu, China | |
| Brand Name | CS | Model Number | JYPL | |
| Voltage | 380V/50HZ or at optoinal | Power(W) | TBC | |
| Dimension(L*W*H) | 30m | Weight | 25-35T | |
| Certification | ISO9001 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
PLASTIC MONOFILAMENT YARN EXTURDER MACHINE
PP PE FLAT FILM YARN MAKING MACHINE AND STRETCH LINE
PP PE FLAT FILM YARN EXTRUDER MACHINE
Advantage for pp/pe flat monofilament yarn making and stretch machine
This line is designed and manufactured on the basis of world advanced technology and long-term experience.With super-high capacity,high quanlity,high efficiency,low consumption,it can reach the minimum personnel cost and site area.Especially in producing PP/PE special yarn,such as PE tarpulin,warp yarn for jumbo bag etc,this line has more competition power. The capacity of this line is double than other normal tape line.
Main technical parameter:
| Item | SJPL -500 | SJPL-650 |
| Max extrusion volume | 500kg/h | 650kg/h |
| Screw Diameter | 100mm | 110mm |
| Ratio of L/D | 33:1 | 33:1 |
| Rotation speed of screw | 20-120r/min | 20-120r/min |
| Length of mold lip | 1100mm | 1500mm |
| Max production speed | 550m/min | 550m/min |
| Flat yarn fibre scope | 60-200tex | 60-200tex |
| Drawing ratio | 4-10 | 4-10 |
| No.of winder | 170Spindles | 210Spindles |
| System installed capacity | 350kw | 460kw |
| System normal operational capacity(about) | 210kw | 276kw |
| Overall dimension(L×W×H) | 34000×3700×3000mm | 35000×3900×2600mm |
| Total weight | 27T | 32T |
