Elisa Reader and Washer

FOB Price

US$ 1,500 - 2,500 / Piece

1 Piece(Min. Order)

Port SHANGHAI
Payment TermsT/T D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Biochemical Analysis System		Brand Name	DRAWELL
Model Number	DW-SM600

Product Description

DW-SM600 Microplate Reader

It is controlled by computer to complete Enzyme Linked Immunosorbent Assay (ELISA). Read 96 well microplate, analyse and report, which is widely used in clinical diagnostic laboratories, centers for disease control and prevention, animal and plant quarantine, animal husbandry and veterinary epidemic prevention stations, biotechnological industries, food industries, environmental science, agricultural scientific research and other academic organizations.

Features:
-Large LCD display, with touch screen.

   -8-channel optical fibers system enables rapid reading for 96-well plate.
   -Calculation Method: Factor Method, Linear Regress, Quadratic Curve, Point to Point, Exponential Function, Logarithmic Function, Cubic Spline Curve.
   -96-well plate, with PC software. It can achieve multiple tests in the single plate.
   -Plate shaking, speed and time adjustable.

-Test method: ABS, Qualitative, Level, Quantitative, Kinetic Quantitative.
-Plate shaking, speed and time adjustable.

-User-friendly operation software (Optional): With PC software, it can achieve input/ query patient information, input/query test results, print patients report, automatically save the Quality control data, make quality control chart, set microplate parameter, do Qualitative and quantitative detection. We also provide the scientific research professional software, test data can be import and export functions in MS Excel for further analysis.

Main Specifications

Display	240×128 LCD ( touch Screen )
Interface	RS232 9 needle
Suitable microplate type	96 wells, Flat bottom, U bottom, V bottom
Shake	3 kinds of intensity (High, Medium, Low)
Memory	200 programs, 1000 plates result
Light Source	12V,20W Halogen
Wavelength range	400nm to 750nm
Optical sensor	8 photodiode
Standard filters	Interference filter 405,450,492,630nm
Reading speed	Single wavelength 6 sec. Double wavelength 10s
Absorbance range	0.000 to 3.500 ABS
Resolution	0.001 ABS
Absorbance stability	±0.003 Abs
Accuracy	ΔA≤±0.01 Abs(0≤A<1.0 Abs); ≤2.5%(1.0 Abs≤A≤2.5 Abs);
Sensitivity	≥0.01
Repeatability difference	≤0.2% (0≤A≤1.5 Abs); ≤1.0% (1.5 Abs <A≤2.5 Abs);
Channel difference	≤0.02 Abs
Linearity	≥0.999
Internal printer	58mm thermal printer
Voltage	AC 220V, 50Hz
Power	90 VA
Size	318286168mm
Weight	6.5Kg
Working temperature	10℃—30℃
Working humidity	≤ 85%
Storage temperature	0℃—55℃
Storage humidity	≤ 95%
