Mine underground infrared methane CH4 gas alarm
- 12000 Piece / Pieces per Month
- Qingdao
- Credit Card
You May Like
-
PIR-800 Intelligent integrated protective device for power supply
-
China mine GYXH1000 ethylene sensor
-
Hot sale GUCS10 Ultrasonic liquid level sensor for export
-
Switching Transducer/Output sensor switch GKT5L
-
ZBL-L Low voltage leakage protection device safety product
-
Mining Dust concentration sensor GCG1000 price,digital sensor
Product Details
| Place of Origin | Shandong, China | Brand Name | Bafang | |
| Model Number | JHB-100 | Usage | Other |
Product Description
Mine underground infrared methane CH4 gas alarm
JHB-100 used advanced infrared sensor, which can detect the concentration of
Methane (CH4) in various environments. Wide application covers gas safety inspection and alert for industrial scene, such as petroleum refinery, chemical plants, LPG stations, boiler rooms, gas stations, paint spray booths, etc.
Specifications
1.Swift delivery.
2.Competitive price.
3.OEM/ODM.
4.Imported sensor.
Working Environment
Pressure 86~102Kpa
Working Temp 0~40°C
Humidity ≤95%RH
Power Supply DC3.7V
Lithium battery 1300mAh
standby time 10 hours
Features
High stability, long calibrating period, minimal maintenance time;
Wide detecting range, there will be no impact failure caused by the high concentration CH4 gas;
Can work in oxygen-free environment;
No intoxication, long performance time;
Rapid and accurate measurement, high selectivity to gas types, little interference by other gases;
Delivery Detail : Within 7 days after receive your payment
Packaging Details : Standard package or as customers' requirement
Technical Specifications
Applicable Gas | Methane (CH4) |
Detecting Range | 0~5%VOL & 0~100%VOL |
Resolution | For 0-5%vol, resolution is 0.01% For 100%vol, resolution is 1% |
Limits of error | For 0~1% CH4, ≤±0.1%; For 1~100%CH4, ≤±10% of the truth value |
Preheat Time | 30s |
Response Time (T90) | <25s |
Storage Temperature | -40°C~85°C |
Operating Temperature | -20°C~65°C |
Humidity | ≤95%RH |
Standby Time | ≥10h |
Power Supply | Lithium battery DC 3.7V 1300mAh |
Dimension | 93mm*62mm*25mm |
