2016 New Pre-Painted Steel Coils /Sheets (PPGI)

50μm

Polyethylene

Protecting from scratchs and contamination

(option)

20μm

Polyester Fluorine

Chemical resistance and formability

Primer coat

5μm

Polyester

Workability, corrosion resistance and adhesion to the primer coating

1μm

Good adhesion and corrosion resistance

0.13mm-0.6mm

GI.GL,AL

GI.GL,AL

5±2μm

Epoxy

Corrosion resistance and adhesion to the substrate

Techinical Standard:

ASTM A792

Grade

DX51D+AZ,  SPCC, SGCC, SECC

Types:

Commercial / Drawing / Deep Drawing / Structural quality

Thickness

0.13-0.6mm

Width

600--1250mm

Type of coating:

galvalume (AL-zinc)

Zinc coating

AZ40-180g/m2

Surface treament

chromed with passivation / environmental chromed

oiled/slightly oiled/ dry/ anti-fingerprint/ skinpassed

Zincalume with protection film (35 µ, Nominal Adhesion 265 gr/ 50mm)

Based metal: Steel Sheet, 55% Aluminum-Zinc alloy coated in Coils

ID coil

508mm or 610mm

MOQ

minimum 25 MT for each size

Supply capacity:

250000MT per year

Package:

Properly packed for ocean freight exportation in containers

Application:

Industrial panels, roofing and siding for painting

Price terms

FOB,CFR,CIF

Payment terms

30%TT in advance+70% TT or irrevocable 70%L/C at sight

delivery time

35 days after receipt deposit

Remarks

Insurance is all risks

MTC 3.1 will be handed on with shipping documents

We accept SGS certificatation test
