Mining moving cart

Specifications

Mining moving cart

structure and working principle

Tipping bucket tub KFU0.75-6 type trunks, frame, round, 40mm bolt connection.

1, carriages: box board, cover, lip angle iron welded.

2, Frame: channels, angles, meet, axis cards welding.

3, wheel: the wheel, shaft, bearings and other components.

Specification:

Model            0.55V Cart   0.6U Cart   0.75V Cart  0.85V Cart   IM3V Cart

Capacity(m3):   0.55          0.6           0.75          0.85           1

Working Weight(Ton): 1.375        1.5          1.875         2.125        2.500

Gauge(mm):         600            600          600           600           600

Wheelbase(mm):     500            500          550           600           650

Wheel dia,(mm):     650          650           650            650          650

Height(mm):         320           320           320            320          320

Unload angle:      42            40             43            42           42

Real weight(Ton): 0.533         0.548          0.6          0.658         0.748

Siza(mm):  1600 *960*1245  2137*1160*1225  1860*960*1245  1925*960*1248   2278*960*1248

Connect type: Single cinnection Single connection Single cinnection Single connection Single cinnection Single cinnection
