Longlife Automatic Paste and Liquid Filling Machine With a Foot Switch and Auto- Filling From Kunchi for Sale
- any port of china
- T/T Credit Card
You May Like
-
Industrial Aluminum Foil Induction Capper With Good Price
-
High Precision, Simple Structure, Convenient Operation Paste and Liquid Filling Machine
-
Best Sold Aluminum Foil Induction Sealing Machine With Good Quality and Best Price
-
Automatic Simple Structure and Convenient Operation Paste and Liquid Filling Machine
-
ISO9001 Best Paste and Liquid Filling Machine for Sale
-
High Quality Industrial Paste and Liquid Filling Machine With High Qualit and Best Price
Product Details
| Application | Food, Commodity, Medical, Chemical | Packaging Type | Bottles, Stand-up Pouch, Bags | |
| Packaging Material | Plastic, Metal | Automatic Grade | Automatic | |
| Driven Type | Electric | Voltage | 380V | |
| Place of Origin | Henan, China | Brand Name | KUNCHI | |
| Model Number | JF-I-60 | Dimension(L*W*H) | 700*250*300mm | |
| Weight | 13kg | Certification | ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
paste and liquid filling machine1.piston made of PTFE material pneumatic parts
2.with a foot switch and auto- filling
longlife automatic Filling machine with a foot switch and auto- filling from Kunchi for sale
Work principle of paste and liquid filling machine
A. Through the cylinder's movement of forward and backward to make the piston which is located in the cylinder do reciprocating movement,
so as to occur the negative pressure in the preceding chest of the cylinder
B. The piston is pulled backward when the cylinder make forward movement, the material cylinder occurred negative pressure,
the materials in the barrel are pressed into the feeding pipe by pressure and go into the material pipe through unidirectional valve of feeding and discharging materials.
C. The piston is driven forward when the cylinder make backward movement, the materials are pressed and go into discharging pipe through unidirectional valve of discharging materials,
finally filled into the empty bottle which need to be filled, then one time filling finished.
D. It is a single and simple action to each time of filling for the piston filling machine, so it has very high filling precision and stability to every regular container
Features of paste and liquid filling machine
1.The liquid filling machine cylinder, cabinet, hopper are made of stainless steel ,and the piston made of PTFE material pneumatic parts are imported components, compliance with GMP requirements.
2.Paste filling machine filling volume and filling speed can be adjusted, with a foot switch and auto- filling features.
3.Paste filling machine with high precision, simple structure, convenient operation.
Application of paste and liquid filling machine
This series of horizontal pneumatic semi-automatic paste filling machine widely used for chemical, food, cosmetic,
pharmaceutical, pesticide, oil and other industries liquid, paste, sauce, granular materials’ quantitative filling.
the series of equipment suitable for filling materials (The same type of material, shapes may vary, the form below is for reference only | ||||||
Food category | Oil class | Daily necessities | Cream class | Emulsion class | Seasoned class | Other class |
Pure water Distilled water Running water Juice Tea with milk Juice Drinks Jelly Health wine Treasure soup Chicken soup Cream Blend oil Colza oil Tea seed oil Soybean oil Corn oil .. .. .. | Edible oil Fatty oil Volatile oil Machine oil Gear oil Hydraulic oil Lubricating oil Oil Rust oil Rail oil Heat Conduction oil Mold release oil Insulating oil Brake oil Recovery oil Waste oil Pine oil Grease
| Body wash Shampoo Hair conditioner Baked ointment Skin toner Facial cleanser Massage oil Washing fluid Essence milk Liquid Collars NET Softener Bleach Fragrance liquid Toothpaste
| Paste Extract Cleaning agents Protective agent Additive Active agent Healing agent Coupling agent Flux Glass liquid Braked fluid Antifreeze Coolant
| Dye hair cream Cleansing cream Skin cream Hand cream Sunscreen Essence cream Segregation frost Cream Lip balm Solder paste Soft cream Milk cream Vanishing cream Chilblain ointment Deodorant
| Sesame paste Peanut butter Tomato sauce Soybean paste Seafood sauce Fruit sauce Seasoning Sauce Flavoring agent Sweeteners Preservative Brightener Thickener Juice Concentrate Spices Essence Soy sauce Vinegar
| Resin Fill fetal liquid Cleaning cream Color paste Puree pulp slurry Curing agent Defoamer Resin adhesive Pesticides Medicine glue Extract honey Royal jelly |
Technical parameter of filling machine
Single-head:
Model | JF-I-60 | JF-I-125 | JF-I-250 | JF-I-500 | JF-I-1000 | JF-I-2500 | JF-I 5000 |
Air supply | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa |
Filling volume | 3-60ml | 10-125ml | 10-250ml | 20-500ml | 50-1000ml | 100-2500ml | 200-5000ml |
Filling speed | ≤30pcs/min | ≤30pcs/min | ≤30pcs/min | ≤20pcs/min | ≤20pcs/min | ≤15pcs/min | ≤12pcs/min |
Material | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 |
Weight | 13kg | 14kg | 16kg | 18kg | 22kg | 28kg | 35kg |
Packing size(mm) | 700*250*300
| 800*250*320
| 1200*300*350 | ||||
Two-head:
Model | JF-II-60 | JF-II-125 | JF-II-250 | JF-II-500 | JF-II-1000 | JF-II-2500 | JF-II-5000 |
Air supply | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa | 0.4-0.6Mpa |
Filling volume | 3-60ml | 10-125ml | 10-250ml | 20-500ml | 50-1000ml | 100-2500ml | 200-5000ml |
Filling speed | ≤60pcs/min | ≤60pcs/min | ≤60pcs/min | ≤40pcs/min | ≤40pcs/min | ≤30pcs/min | ≤30pcs/min |
Material | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 |
Weight | 22kg | 24kg | 27kg | 32kg | 36kg | 40kg | 52kg |
Packing size(mm) | 700*420*300
| 800*420*320
| 1200*500*350 | ||||
Picture show of filling machine
